KNX – Mitsubishi Heavy Industries AC
TM
Intesis
Behavior of Intesis TM
by means of flags (R, W, T, U and U2), explained in section 4.2.2.
Additional to the binding aspect commented above, it is also important to notice that each
KNX communication object has a defined EIS type. The EIS type of a communication object
defines the bit length and coding of the data it represents. Communication objects
associated by means of a group address need to match the same EIS type, in order to
communicate consistently.
So, at configuration time it is required that for each datapoint configured on Intesis
type is defined. Datapoints on Intesis
• EIS1 - Switching (1bit raw)
• EIS2 - Dimming (4bit raw)
• EIS5 – Value (16bit – floating type)
• EIS6 – Scaling (8bit – scaled 0%-100% in values 0-255)
• EIS7 – Drive Control (1bit raw)
• EIS8 – Priority (2bit raw)
• EIS9 – IEEE 754 float (32bit – floating type)
• EIS10 – 16bit Counter (16bit raw)
• EIS11 – 32bit Counter (32bit raw)
• EIS13 – ASCII char (8bit raw)
• EIS14 – 8bit Counter (8bit raw)
ETS3 or ETS4 software tools are not used to configure Intesis
choice of which KNX group addresses to use is restricted or defined by an ETS-based
project. If that's the case, the KNX installer/integrator needs to provide the set of group
addresses prior to doing the configuration of datapoints in LinkBoxEIB.
Also, a dummy ETS application is provided by HMS Networks (section 5), which can be
imported into ETS. This application is nor downloadable into Intesis
Intesis TM configuration. Rather, it poses as a means of having a device in the ETS project
representing the Intesis
group addresses are associated.

Communication objects available

Address map is configurable for each indoor unit and can be modified through the supplied
software LinkBoxEIB.
datapoints/communication objects available either for each indoor unit control or all indoor
units control at a time. Please, remember that in the tables R/W stands for Read and Write,
R stands for Read Only and W stands for Write Only.
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
datapoints with regard to their associated group addresses is defined
TM KNX support the following EIS-types:
TM KNX and its own datapoints/communication objects, and to which
Next, there
TM . Though, it's typical that the
TM
are two tables
User's Manual r1.2 eng
TM an EIS
KNX neither usable for
showing different
