Intesis TM KNX Device Connections
3
2
12
13
Next, there is the list with the device physical interface connector's description
1.- KNX configuration Port
2.- Non supported
(C2)
3.- Console serial port EIA232
4.- Operation LED
5.- Error LED
6.- Host LED
7.- Pac LED
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
8
4 5 6
7
1
Figure 3.1 Intesis
100-240VAC~
50-60Hz 5W max
Figure 3.2 Intesis
(C1)
9
10
TM KNX device front view
FUSE:
250V 1.5A(T)
20x5mm
TM KNX device back view
8.- Reset button
(Non supported)
9.- Superlink selector (SLK)
New: Superlink-II
Old: Superlink-I
10.- A-B connector
(for Superlink, no polarity)
11.- IP configuration Ethernet (ETH)
12.- Power supply On/Off button
13.- Power supply fuse (250V, 1.5A)
14.- Power supply connector
User's Manual r1.2 eng
11
14
