Capacity Of Intesis Tm - HMS Networks Intesis INKNXMHI048O000 User Manual

KNX – Mitsubishi Heavy Industries AC
TM
Intesis
Capacity of Intesis
Element
Number of indoor units
Main Group Address
Total number of listening group
addresses
Num. of listening addresses per
communication object
* There are two different models of Intesis
one with different capacity. The table above shows the capacity for the top model (with
maximum capacity).
Their order codes are:
INKNXMHI048O000:
▪
Model supporting up to 48 indoor units
▪
For Superlink-I (Previous Superlink) or Superlink-II (New Superlink).
▪
Indoor Unit actual address range is 00 to 47
▪
INKNXMHI128O000:
▪
Model supporting up to 128 indoor units
▪
For Superlink-II (New Superlink)
▪
Indoor Unit actual address range is 000 to 127
▪
Check available combination of Mitsubishi Heavy Industries Central Control and BMS
interface units in the next tables.
In the case of SL2NA or SL3NA, it is necessary to erase registration of non-connected indoor
unit. For SL2NA and SL3NA, change is required for the setup deprived of the rights of
instruction of Remocon control Lock/Unlock.
New Superlink connections:
MH-AC-MBS-128 SC-LGWNA-A
INKNXMHI128O0 SC-BGWNA-A/B
00
1 Non connect
MH-AC-MBS-48 SC-LGWNA-A
INKNXMHI048O000 SC-BGWNA-A/B
1
Previous Superlink connections:
MH-AC-MBS-48/128
INKNXMHI048O000/128
1
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
TM
Max.
128 *
3000
1000
255
Table 1.1 Intesis
SC-SL3NA-AE/BE
etc.
etc.
2
1
0
SC-SL3NA-AE/BE
etc.
etc.
2
Non connect 1
0
SC-LGWNA-A SC-SL3NA-
SC-BGWNA-A/B AE/BE
etc.
Non connect Non connect
Notes
Maximum number of AC indoor units that
can be controlled
Maximum number
objects
Number of KNX groups that can be used as
listening addresses
Number of listening addresses that can be
associated to an KNX group address
TM capacity
TM KNX – Mitsubishi Heavy Industries AC each
SC-SL2NA-E SC-SL1N-E
etc.
0
0-2
0-4
SC-SL2NA-E SC-SL1N-E
etc.
0
0-2
0-4
SC-
SL2NA-E
etc. etc.
1
0
0
User's Manual r1.2 eng
of communication
Max
etc. Indoor
Units
0-8 128
Max
etc. Indoor
Units
0-8 48
SC-SL1N-E Max
etc. Indoor
Units
0
32
1,2
0 48
URL https://www.intesis.com
Address
No.
000-127
Address
No.
00-47
Address
No.
00-47
7 / 26
