KNX – Mitsubishi Heavy Industries AC
TM
Intesis

Description

Introduction

Intesis TM KNX – Mitsubishi Heavy Industries AC is a communication gateway for the
integration of Mitsubishi Heavy Industries air conditioning (AC) systems into KNX TP-1
(EIB).
This gateway allows integrating a Mitsubishi Heavy Industries AC system inside a
supervision/control/automation system through PLC, SCADA and, in general, through any
device or system with a KNX TP-1 (EIB) interface.
The aim of this integration is to make accessible several Mitsubishi Heavy Industries air
conditioning indoor units communicating with the Superlink protocol as if they were part of
a KNX TP-1 (EIB) system. Therefore, the Intesis
1 (EIB) interface, allowing the KNX system read and write in the communication objects.
Moreover, Intesis TM
Industries indoor units without extra components needed.

Integration signals

Following is the list of parameters that can be monitored/controlled on the indoor units
using Intesis TM :
For each indoor unit in the system:
▪
Communication Status (read-only)
o
On/Off (R/W)
o
Operation Mode (R/W)
o
SetPoint Temperature (R/W)
o
Fan Speed (R/W)
o
Remocon Lock/Unlock (R/W)
o
Louver Control (R/W)
o
Room Temperature (read-only)
o
Filter Sign Status (read-only)
o
Error Code (read-only)
o
Compressor Status (read-only)
o
Filter Sign Reset (write-only)
o
Remocon Error Reset (write-only)
o
Thermo On/Off Status (read-only)
o
Apart from these, the Intesis
For all indoor units
▪
HW Communication Status (read-only)
o
On/Off (write-only)
o
Operation Mode (write-only)
o
SetPoint Temperature (write-only)
o
Fan Speed (write-only)
o
Remocon Lock/Unlock (write-only)
o
1 These signals work as master signals controlling all connected units at the same time
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
includes all hardware required to manage/control Mitsubishi Heavy
TM also implements some extra signals (functions):
1 in the system:
TM KNX acts as a KNX device in the KNX TP-
User's Manual r1.2 eng
