Software Checking - HMS Networks Intesis INKNXMHI048O000 User Manual

KNX – Mitsubishi Heavy Industries AC
TM
Intesis
2.- Check Intesis
LED Status
OP
Off
Blinking once
ERR
periodically
HOST
Off
PAC
Off

6.3.2 Software checking

Once physical connections have been checked, if functioning problems still remain, please
use the LinkBoxEIB tool to monitor the working status of the device.
• To check the KNX communication status, click on the KNX button in the menu
bar (see Figure 4.1).
• To check the MHI communication status, click on the MHI button, also in the
menu bar (see Figure 4.1).
• To check the signal values in the KNX communication objects, click on the
Signals button, also in the menu bar (see Figure 4.1).
Further information regarding the monitoring procedure and the information provided in
each window can be consulted in the LinkBoxEIB Manual.
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
TM LED status:
Explanation
No power reaching the
internal device
Superlink
communication failure
Configuration error
Communication error in
the Superlink network
Table 6.1 Intesis TM
Solution
Check power connection
Check fuse status
Check Superlink cables and terminals
(connectors, length of cables, etc.)
Download the binary file again
Check the Mitsubishi Heavy Industries
Superlink network and its connections
LED status information
User's Manual r1.2 eng
see part 13 in Figure 3.2
( )
(see 4.3)
URL https://www.intesis.com
23 / 26
