KNX – Mitsubishi Heavy Industries AC
TM
Intesis
Enclosure
Color
Power
Fuse
Terminal wiring
(for low-voltage
signals)
Mounting
KNX port
A-B port
ETH port
LED indicators
Push buttons
Selectors
Console port
Configuration
Firmware
Operational
temperature range
Operational
humidity range
Protection
RoHS conformity
Norms and
standards
Table 7.1 Intesis

AC Unit Types compatibility

Indoor units compatible with the Intesis
included in the Mitsubishi Heavy Industries KX family and so on.
1
A power cable with connector C14 male 1.6 meters long is supplied with the device.
2
Standard cable DB9male-DB9female 1.8 meters long is supplied with the device for connection to a PC COM port for configuring
and monitoring the device. The configuration software, compatible with Windows
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
Industrial sheet metal.
Size: 215mm x 167mm x 61mm.
Weight: 2.025 Kg
Gray metalized.
100 to 240VAC~
50 to 60Hz
5W max.
Power connector: C14 (male)
250V
1.5A
Dimensions: 20x5mm
Per terminal: solid wires or stranded wires (twisted or with ferrule)
1 core: 0.75 ... 1.25mm
2 cores: 0.75 ... 1.25mm
3 cores: not permitted
Wall (see Figure 7.3)
1 x KNX TP1 (EIB) opto-isolated (Plug-in screw terminal block 2
poles)
1 x Superlink terminals (Plug-in screw terminal block 2 poles "A"
"B"). SELV
1 x Ethernet 10Base-T (RJ45)
2 x Ethernet port link and activity (LNK, ACT).
4 x MHI Interface (OP, ERR, HOST, PAC)
1 x Reset Device
1 x SLK selector
EIA232. (DB9 female DCE). SELV
Via console port. 2
Allows upgrades via console port.
0°C to +40°C
5% to 95%, non condensing
IP20 (IEC60529).
Compliant with RoHS directive (2002/95/CE).
CE conformity to EMC directive (2004/108/EC) and Low-voltage
directive (2006/95/EC)
EN 61000-6-2
EN 61000-6-3
EN 60950-1
EN 50491-3
TM Mechanical and Electrical Characteristics
TM
1
2
2
KNX – Mitsubishi Heavy Industries are those
TM
operating systems, is also supplied.
User's Manual r1.2 eng
URL https://www.intesis.com
25 / 26
