DIGITAL POWER STARTER KIT

Chapter 2. Hardware

This chapter describes the hardware components of the Digital Power Starter Kit.
Topics covered include:
Top Assembly
Signal Configuration
Application Components
Board Connectors
Indicators and Human Interfaces
Test Points
Power Rating of Converter Stages
Programmer/Debugger
The top and bottom assembly of the board is shown in
Table 2-1
and
Table 2-2
provide a description of the components.
FIGURE 2-1:
DIGITAL POWER STARTER KIT (TOP VIEW)
6
7
Figure 2-1
3
1
8
2
USER'S GUIDE
and
Figure
2-2.
5
4
DS52078A-page 19
