53-1004105-13 Hardware Installation Guide
LED Purpose
Slow-flashing amber (on 1.28
seconds, then off 1.28 seconds)
Fast-flashing amber (on 320 ms
second, then of 320 ms)
Alternating green/amber

Interpreting Extension Blade LEDs

See the following figure and table to interpret the LED patterns on the SX6 extension blade. The LED patterns temporarily
change during POST and other diagnostic tests.
Broadcom
Color
Port is disabled due to diagnostic
tests or the
portCfgPersistentEnable
commands.
Transceiver or port is faulty.
Port is beaconing.
Status
Reset the port from the workstation
portDisable
or using the
portCfgPersistentEnable
command.
Change the transceiver or reset the
switch from the workstation.
No action is required.
Brocade X6-8 Director
Hardware Installation Guide
Recommended Action
portDisable
or
53-1004105-13
72
