53-1004105-13 Hardware Installation Guide
FRU
XBR-X6-0164
FC32-64 blade
XBR-CPX6-0103
CPX6 blade
XBR-X68-0106
CR32-8 blade
XBR-SX6-0000
SX6 blade
XBR-X6-0124
WWN card
XBR-X6-0128
Blade slot filler
panel
Power supply
XBR-X6-0130
assembly slot filler
panel
Table 2: Rack Mount Kits
Kit
Rack mount kits

Notes, Cautions, and Danger Notices

Notes, cautions, and danger statements may be used in this document.
NOTE
A Note provides a tip, guidance, or advice, emphasizes important information, or provides a reference to related
information.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause damage to
hardware, firmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to
you. Safety labels are also attached directly to products to warn of these conditions or situations.
Contacting Technical Support for Your Brocade
If you purchased Brocade product support from a Broadcom OEM/solution provider, contact your OEM/solution provider
for all your product support needs.
Broadcom
Part Number
Port blade with 16 QSFP+ FlexPorts
that can be configured for FC or FCoE
operation. Each port can operate at speeds
up to 4x32G port for a total of 64 32G
ports per blade with FC transceivers
installed. Optionally, you can install Ethernet
transceivers and configure them for
FCoE operation. Various GbE speeds are
supported.
Control processor (CP) blade
Core routing (CR) blade with 16 4x32G
QSFP+ ports for Brocade X6-8 Director.
Extension (X) blade with 16 32G Fibre
Channel SFP+ ports, 16 10GbE SFP+ ports,
and 2 40GbE QSFP+ ports
World Wide Name card
Required to cover empty slot to maintain
airflow in chassis.
Required to cover empty slot to maintain
airflow in chassis.
Part Number
XBR-DCX-0121
XBR-DCX-0120
XBR-DCX-0152
Short Description
Mid-mount rack mount kit for two-post rack
14U rack mount kit for four-post rack (27–31 in.)
14U rack mount kit for four-post rack (22 in.)
Introduced (OS) Currently Supported
Fabric OS 8.2.0
Fabric OS 8.0.1
Fabric OS 8.0.1
Fabric OS 8.0.1
Fabric OS 8.0.1
Fabric OS 8.0.1
Fabric OS 8.0.1
Short Description
®
Product
Brocade X6-8 Director
Hardware Installation Guide
Yes
Yes
Yes
Yes
Yes
Yes
Yes
53-1004105-13
10
