Installation and User Guide
Y14 #5 Manually On/Of Start or Stop control mode .
Caution: this mode may cause overheating and
damage!
H9 Channel #5 > Channel ON/OFF
Y15 #5 Channel ON/OFF If OFF – symbol # in the
line, algorithm is stopped, but real Temp . is
being shown
H11 Channel #5 > Sensor type
Y17 #5 Sensor type
H12 Channel #5 > Relay Status RO/RC
Y18 #5 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status 'Heating On'
H13 Channel #5 > Relay Test 5/30 sec .
Y19 #5 Relay Test 5/30 - Every 5 sec . switching for 30 sec .
Z1 Channel #6 > Regulation Type
T1 #6 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
Z2 Channel #6 > Temp & Hysteresis
T2 #6 Set Temperature
T3 #6 Set +-Hysteresis
Z3 Channel #6 > On Time & Period
T4 #6 Set On Time
T5 #6 Set PR Period (max . 900 minutes)
Z4 Channel #6 > Alarm Temps & En/Dis
T6 #6 Alarm Temp En/Dis
T7 #6 Alarm min . Temp
T8 #6 Alarm max . Temp
Z5 Channel #6 > CableOK?
T9 #6 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
T10 #6 CableOK? = NO/NC . Set up DI6 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
Z75 Power calculator > Channel Power #6
T11 #6 Channel Power (max . 32000)
Z8 Channel #6 > Manually On/Of
T12 #6 Manually On/Of Time – Set up period of time
for MOn or MOf status (max . 900 minutes)
T13 #6 Status On or Of for mode Heating Manually
T14 #6 Manually On/Of Start or Stop control mode .
Caution: this mode may cause overheating and
damage!
Z9 Channel #6 > Channel ON/OFF
T15 #6 Channel ON/OFF If OFF – symbol # in the
line, algorithm is stopped, but real Temp . is
being shown
42
DEVIreg™ Multi
0 1
0 1
0 7
0 1
0 1
0 1
-50 200
0 .2 6
1 0
0 900
0 1
-50 0
0 200
0 1
0 1
0 32000
1 900
0 1
0 1
0 1
0 – STOP Enum 6
0 – OFF Enum 7
1 – PT1000 Enum 9
0 – RC Enum 10
0 – STOP Enum 6
1 – 1S Enum 1
5 °C
0 .4 °C
15 min .
30 min .
0 – Dis Enum 5
0 °C
60 °C
0 – Dis Enum 5
1 – NO Enum 8
0 W
1 min .
0 – Of Enum 11
0 – STOP Enum 6
0 – OFF Enum 7
FEC | Produced by Danfoss ©
RW 3093
RW 3094
RW 3095
RW 3096
RW 3097
RW 3098
RW 3099
RW 3100
RW 3101
RW 3102
RW 3103
RW 3104
RW 3105
RW 3106
RW 3107
RW 3108
RW 3109
RW 3110
RW 3111
RW 3112
