Installation and User Guide
Parameters setting for PR mode can be done by the following menu sequence:
EN: Main Screen – Enter to Main Menu – Channels settings – Channel #X – On Time
& Period – { Enter – #X Set On Time – Down – #X Set PR Period }
EN: Main Screen – Enter to Main Menu – Channels settings – Channel #X – On Time
& Period – { Enter – #X Set On Time – Down – #X Set PR Period }
Line of the Main screen with PR mode data for one Channel is shown on the picture below:
4.4.5 MOn and MOf – Manually heating On and Manually heating Of mode
Manually On/Of mode (on the screen – MOn or MOf) is control with setting time period
during which heating will be turned on or turned off . This mode can be started only on
the base of 1S or PR mode and after Manually On/Of mode is finished, controller returns
to the same initial mode – 1S or PR .
This mode can be individually set up for any Channel .
Three control parameters can be set up: time period, heating state – On or Of, and Start
or Stop mode state .
Time Period . Setting Period of time for MOn or MOf mode . Default – 1 min .
Heating status . Setting state Heating On or Heating Of . Default – Of .
Start or Stop . Starting or Stopping control mode . After finishing of MOn or MOf mode
controller goes to Stop state automatically and disappears from the screen automatically
too . Default – Stop .
NB: It is the full responsibility of the installer/user to use this mode and to set up correct states that
correspond to the specific application to avoid overheating of the cable, building materials and so on.
FEC | Produced by Danfoss ©
DEVIreg™ Multi
Time from Heating status:
the beginning
of the Period (min.)
On Time
On or Of (min.)
Period
(min.)
23
