Installation and User Guide
Z11 Channel #6 > Sensor type
T17 #6 Sensor type
Z12 Channel #6 > Relay Status RO/RC
T18 #6 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status 'Heating On'
Z13 Channel #6 > Relay Test 5/30 sec .
T19 #6 Relay Test 5/30 - Every 5 sec . switching for 30 sec .
X1 Channel #7 > Regulation Type
V1 #7 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
X2 Channel #7 > Temp & Hysteresis
V2 #7 Set Temperature
V3 #7 Set +-Hysteresis
X3 Channel #7 > On Time & Period
V4 #7 Set On Time
V5 #7 Set PR Period (max . 900 minutes)
X4 Channel #7 > Alarm Temps & En/Dis
V6 #7 Alarm Temp En/Dis
V7 #7 Alarm min . Temp
V8 #7 Alarm max . Temp
X5 Channel #7 > CableOK?
V9 #7 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
V10 #7 CableOK? = NO/NC . Set up DI7 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
X75 Power calculator > Channel Power #7
V11 #7 Channel Power (max . 32000)
X8 Channel #7 > Manually On/Of
V12 #7 Manually On/Of Time – Set up period of time
for MOn or MOf status (max . 900 minutes)
V13 #7 Status On or Of for mode Heating Manually
V14 #7 Manually On/Of Start or Stop control mode .
Caution: this mode may cause overheating and
damage!
X9 Channel #7 > Channel ON/OFF
V15 #7 Channel ON/OFF If OFF symbol # on the
main screen, algorithm is stopped, but real
Temp . is shown
X11 Channel #7 > Sensor type
V17 #7 Sensor type
X12 Channel #7 > Relay Status RO/RC
V18 #7 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status 'Heating On'
X13 Channel #7 > Relay Test 5/30 sec .
V19 #7 Relay Test 5/30 - Every 5 sec . switching for 30 sec .
FEC | Produced by Danfoss ©
DEVIreg™ Multi
0 7
0 1
0 1
0 1
-50 200
0 .2 6
1 0
0 900
0 1
-50 0
0 200
0 1
0 1
0 32000
1 900
0 1
0 1
0 1
0 7
0 1
0 1
1 – PT1000 Enum 9
0 – RC Enum 10
0 – STOP Enum 6
1 – 1S Enum 1
5 °C
0 .4 °C
15 min .
30 min .
0 – Dis Enum 5
0 °C
60 °C
0 – Dis Enum 5
1 – NO Enum 8
0 W
1 min .
0 – Of Enum 11
0 – STOP Enum 6
0 – OFF Enum 7
1 – PT1000 Enum 9
0 – RC Enum 10
0 – STOP Enum 6
RW 3113
RW 3114
RW 3115
RW 3116
RW 3117
RW 3118
RW 3119
RW 3120
RW 3121
RW 3122
RW 3123
RW 3124
RW 3125
RW 3126
RW 3127
RW 3128
RW 3129
RW 3130
RW 3131
RW 3132
RW 3133
