4.4.11 Relay Counters view and reset

DEVIreg™ Multi controller is collecting information about number of times the Channel
relay is turned on .
Relay counters information can be found in two ways .
The simplest way to see 'Relay On cycles' in total can be done by sequence:
EN: Main Screen – Up .
EN: Main Screen – Up.
For example, the screen view can be as below:
The second way to see list of service information can be done by the following menu
sequence:
EN: Main Screen – Enter to Main Menu – Channels data – Channels data #X –
{ Down – Down } .
EN: Main Screen – Enter to Main Menu – Channels data – Channels data #X – { Down
– Down }.
For example:
