Installation and User Guide
Q1 Channel #1 > Regulation Type
P1 #1 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
Q2 Channel #1 > Temp & Hysteresis
P2 #1 Set Temperature
P3 #1 Set +-Hysteresis
Q3 Channel #1 > On Time & Period
P4 #1 Set On Time
P5 #1 Set PR Period (max . 900 minutes)
Q4 Channel #1 > Alarm Temps & En/Dis
P6 #1 Alarm Temp En/Dis
P7 #1 Alarm min . Temp
P8 #1 Alarm max . Temp
Q5 Channel #1 > CableOK?
P9 #1 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
P10 #1 CableOK? = NO/NC . Set up DI1 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
Q75 Power calculator > Channel Power #1
P11 #1 Channel Power (max . 32000)
Q8 Channel #1 > Manually On/Of
P12 #1 Manually On/Of Time – Set up period of time
for MOn or MOf status (max . 900 minutes)
P13 #1 Status On or Of for mode Heating Manually
P14 #1 Manually On/Of Start or Stop control mode .
Caution: this mode may cause overheating and
damage!
Q9 Channel #1 > Channel ON/OFF
P15 #1 Channel ON/OFF If OFF – symbol # in the
line, algorithm is stopped, but real Temp . is
being shown
Q11 Channel #1 > Sensor type
P17 #1 Sensor type
Q12 Channel #1 > Relay Status RO/RC
P18 #1 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status 'Heating On'
Q13 Channel #1 > Relay Test 5/30 sec .
P19 #1 Relay Test 5/30 - Every 5 sec . switching for 30 sec .
W1 Channel #2 > Regulation Type
O1 #2 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
W2 Channel #2 > Temp & Hysteresis
O2 #2 Set Temperature
O3 #2 Set +-Hysteresis
W3 Channel #2 > On Time & Period
38
DEVIreg™ Multi
0 1
-50 200
0 .2 6
1 0
0 900
0 1
-50 0
0 200
0 1
0 1
0 32000
1 900
0 1
0 1
0 1
0 7
0 1
0 1
0 1
-50 200
0 .2 6
1 – 1S Enum 1
5 °C
0 .4 °C
15 min .
30 min .
0 – Dis Enum 5
0 °C
60 °C
0 – Dis Enum 5
1 – NO Enum 8
0 W
1 min .
0 – Of Enum 11
0 – STOP Enum 6
0 – OFF Enum 7
1 – PT1000 Enum 9
0 – RC Enum 10
0 – STOP Enum 6
1 – 1S Enum 1
5 °C
0 .4 °C
FEC | Produced by Danfoss ©
RW 3008
RW 3009
RW 3010
RW 3011
RW 3012
RW 3013
RW 3014
RW 3015
RW 3016
RW 3017
RW 3018
RW 3019
RW 3020
RW 3021
RW 3022
RW 3023
RW 3024
RW 3025
RW 3026
RW 3027
RW 3028
