Summers CoulterChisel CC2815 Operator's Manual page 147

8J3286 SCRAPER MNT TUBE-86"SCLTR04-
8J5100 #6 JIC(M) X #6 JIC(M) UNION
8J5102 #6 ORB TO 3/8"FPT ADAPTR SWVL
8J5104 #4 ORB(M) X #6 JIC(M) ELBOW
8J5106 #6 JIC TUBE PLUG
8J5110 #10 JIC(M) X #10 JIC(M) UNION
8J5150 3/8" MPT X #6JIC(M)STR ADPTR
8J5152 #8 JIC(F) X #6 JIC(M) RDCR
8J5170 1/2" MPT X #10 JIC(M)STR ADPTR
8J5200 #10 JIC(F) X #6 JIC(M)HEX BUSH
8J5298 TEE #6 SWIVELNUTRUN(M+M+F-SW)
8J5300 TEE #6 JIC (MALE) 3X
8J5312 TEE #10JIC(M2X)X3/4-16ORBBRNCH
8J5500 9/16"-18 ORB X #6 JIC(M) STR
8J5510 3/4"-16 ORB X #6 JIC(M) STR
8J5520 3/4"-16 ORB X #10 JIC(M) STR
8J5540 7/8"-14 ORB X #10 JIC(M) STR
8J5550 1-1/16" - 12ORBX#10JIC(M)STR
8J5600 9/16"-18 ORB X #6 JIC(F-SW)STR
8J5620 3/4"-16 ORB X #6 JIC(F-SW)STR
8J5680 3/4"-16 ORB X 3/4"-16ORB UNION
8J5682 3/4"-16ORB(2X)ADJUSTABLE UNION
8J5690 3/4-16X3/4-16 ORB M-SW90*UNION
8J5700 #6 JIC(F-SW) X #6 JIC(M)90*ADP
8J5710 #10 JIC(F-SW)X#10 JIC(M)90*ADP
8J5800 3/8"FPT X #6 JIC (F-SW) STR
8J5810 1/2"FPT X #10 JIC(F-SW) STR
8J6000 9/16"-18 ORB X #6 JIC(M)90*ADP
8J6002 9/16"-18ORB X #6 JIC(M)BRNCH T
8J6004 9/16"-18ORB X #6 JIC(M)RUN TEE
8J6010 3/4"-16 ORB X #6 JIC(M)90*ADP
8J6020 3/4"-16 ORB X #10 JIC(M)90*ADP
8J6030 7/8"-14 ORB X #10 JIC(M)90*ADP
8J6060 3/4"-16ORB X #6JIC(F-SW)90*ADP
8J7000 BALL VALVE HYD 9/16"-18ORB(2X)
8J7040 THERMAL RELIEF MANIFLD 4000PSI
8J7110 CHECKVLV TNK 7/8-14ORB ML/FML
8J7116 3/4"-16 ORB(2X)1WAY 1/16"RESTR
8J7216 #6JIC(M)X6JIC(F)1/16"RSTR BLKZ
8J7232 #6JIC(M)X6JIC(F)1/32"RSTR Z-08
8J7250 RELIEF VLV 2250PSI 9/16"-18ORB
8J7260 DUAL OUTLET FEMALE HYD COUPLER
8K0050 MNT BRKT ADJ DPRSS MANFLD 12-
8K1100 HUB&AXLE ASSY 614(GBGI-2"RCVR)
8K1105 HUB&AXLE ASSY HD812(2.5"RCVR)
8K1105S HUB&AXLE ASSY HD812 (2"RCVR)
8K1610 PIN 3/4 X 6.25" TRNSPRTLCK 84-
8K1620 PIN 1-1/4 X 6-1/8" 84-
8K1640 PIN 1-1/2 X 10-5/8" HITCH 84-
8K1660 PIN 1-1/2 X 15-1/2" HARDEND84-
8K1720 EYEBOLT 1.25DIAX1"EYE YZ 12-
8K1750 EYEBOLT 1.5"DIAX1"EYE YZ 12-
8K1755 EYEBOLT 1.5"DIAX1.26EYE YZ 12-
8K1900 SEAL GBGI V WALKNG TANDM 01-
8K1920 RETAINING RING 2-7/8" INV 00-
8K2000 BEARING 211 X 2.02" ID 01-
SECTION 7 – PARTS
8K2020
8K2050
8K2080
8K2090
8K2120
8K2128
8K2130
8K2140
8K2150
8K2152
8K2160
8K2165
8K2170
8K2190
8K3002
8K4009
8K4019
8K4130
8K4200
8K4210
8K4300
8K4400
8K4420
8K4922
8K4922N
8K4922S
8K4925
8K4930
8K4935
8K4939
8K4940
8K4944
8K4945
8K4946
8K5200
8K5210
8K5214
8K5350
8K5400
8K5505
8K5515
8K5520
8K7016
8K7020
8K7026
8K7028
8K7033
8K7037
8K7042
8K7111
8K7113
8K7117
8K7118
8K7120
8K7122
8K7123
7-3
RETAINING RING GANG BRNG 84-
GANG BRNG W/HOUSNG 211 X 2"+ID
CAST BEARNG MNT BASE DRILLD
CAST BEARNG PIVOT TUBE DRILLD
GANG ROD 2" DIA X 47"
GANG ROD 2" DIA X 55" CLTR 07-
GANG ROD 2" DIA X 57"
GANG ROD 2" DIA X 67"
GANG ROD 2" DIA X 77"
GANG ROD 2" DIA X 79" CLTR 09-
GANG ROD 2" DIA X 87"
GANG ROD 2" DIA X 91" CLTR 06-
GANG ROD 2" DIA X 97"
GANG ROD 2" DIA X 117"
WRENCH GANG 3-1/8" HEX BLCK00-
SPOOL HALF 2.63" FLAT CLTR 00-
SPOOL HALF 4.8" FLAT CLTR 00-
HOUSING BRG TOGGLE MNT CAST
CLAMP GNGMNT W/PEG CAST PNTD
CLAMP GANG MNT CAST PNTD
CLAMP SCRAPER MNT CAST PNTD
SPRING SHANK GNG MNT 2.5"X1.25
CLAMP FLAT 1/2 X 2- 4-1/4" 84-
BLADE DISK 1/4X22"5BLT4"ID PLN
BLADE DISK 1/4X22" 5BLT NOTCH
BLADE DISK 1/4X22"5BLT4"ID LC
GUARD HUB CAP 517 06-
SPACER 5/8" (7K2065)PNTD 06-
PLATE SNGLDSK(7K2075)PNTD 06-
BRCKT W/517HD AXL RVRSBL 12-
BRCKT W/517AXL SNGLDSK RGHT06-
BRCKT W/517HD HUB RVRSBL 12-
BRCKT W/517HUB SNGLDSK RGHT06-
CLAMP 3 HL DSKCHSL HD HUB 12-
WASHER GANG BOLT 2.03" ID
WASHER GANG W/ 3/4" NC WELDNUT
ROUND 3/4-10NCX 6" STLKFNGR84-
SPLITSTEELBUSH 2" X 1.5"ID- 2"
SPLITSTEELBUSH 4 X 3.5ID- 1.5"
U-BOLT 3/4 X 2-1/8 X 4-1/4" SQ
U-BOLT 3/4 X 4 X 6" SQ
U-BOLT 3/4 X 6-1/8 X 7-1/2" SQ
WHEEL 15 X 8" 8 BOLT-VLV GRD
WHEEL 15 X 10" 8 BOLT-VLV GRD
TIRE 11L X 15" LRF TBLS HWYSRV
TIRE 12.5L X 15" LRF TL HWYSRV
11L X 15 LRF ON 15X8X6 WHEEL
11L X 15 LRF ON 15X8X8 WHEEL
12.5L X 15 LRF ON 15X10X8 WHL
HUB HD812 W/CUPS&ZRK 8BLT3LIP
HUB CAP HD812 DC17
BEARING INNER HD812 LM3780
BEARING OUTER HD812 LM2790
SEAL 2-1/2"ID HD812 SE17 -06
STUD WHEEL 5/8-18UNFX2.5"97-
NUT 5/8"-18UNF WHEEL BOLT 97-
