Summers CoulterChisel CC2815 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CC2815, CC2835, CC2830
DC2815, DC2835, DC2830
IMPORTANT
THE OPERATOR IS RESPONSIBLE
FOR ADJUSTING THE MACHINE SINCE
MACHINE DOES NOT COME "FIELD
READY" FROM FACTORY.
See www.summersmfg.com for the latest version of all Summers Operator's Manuals.
SUMMERS MANUFACTURING CO., INC.
DEVILS LAKE, NORTH DAKOTA 58301 ............................... (701) 662-5391
8Z1095
Operator's
(CoulterChisel & DiskChisel)
WEB SITE: www.summersmfg.com
© Summers Mfg. Co., Inc. 2017
Manual
2009 and newer
CAUTION
READ & UNDERSTAND OPERATOR'S
MANUAL BEFORE USING MACHINE.
®
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CoulterChisel CC2815 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Summers CoulterChisel CC2815

Summary of Contents for Summers CoulterChisel CC2815

  • Page 1 MACHINE DOES NOT COME “FIELD READ & UNDERSTAND OPERATOR’S READY” FROM FACTORY. MANUAL BEFORE USING MACHINE. See www.summersmfg.com for the latest version of all Summers Operator’s Manuals. SUMMERS MANUFACTURING CO., INC. WEB SITE: www.summersmfg.com DEVILS LAKE, NORTH DAKOTA 58301 ....... (701) 662-5391 8Z1095 ©...
  • Page 2 36 months from the date of purchase by the end user from Summers’ dealer. Summers’ obligation is to replace free of charge any part of any product that Summers inspection shows to be defective excluding transportation charges to Devils Lake, ND and return and also excluding all transportation costs from Summers’...
  • Page 3 C. Reference to “right” and “left” in this manual is determined when machine is viewed from the rear. D. Parts are referenced in each drawing with the Summers Manufacturing Part Number. Use this Part Number when ordering replacement parts from your Summers dealer. See back section of manual for description of each Part Number.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SECTION 1 – SAFETY Safety-Alert Symbol ............................. 1-1 General Safety Practices ............................. 1-1 Safety During Transport............................1-2 Safety Decals ..............................1-2 Decals and Their Locations ........................1-2 – 1-6 SECTION 2 – ASSEMBLY General Assembly Instructions ..........................2-1 Safety Alert Symbol .............................
  • Page 5 16’ & 20’ Gang Depth Control Hydraulics ......................6-4 16’ & 20’ Depth Control Hydraulics ........................6-5 16’-28’ Hydraulic Hitch ............................6-6 24’-28’ Centers ..............................6-7 24’-28’ Cylinder Lifts ............................6-8 24’-28’ Transport Assembly ..........................6-9 24’-28’ Hitch and Cylinder Locks ........................6-10 24’-28’...
  • Page 6 NOTES...

  • Page 7: Section 1 - Safety

    SECTION 1 - SAFETY SAFETY-ALERT SYMBOL This symbol is used to denote possible danger and care should be taken to prevent bodily injury. This symbol means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Definition of each Signal Word used in conjunction with the Safety-Alert symbol. indicates an imminently hazardous situation which, if not avoided, will result in death or DANGER serious injury.

  • Page 8: Safety During Transport

    5. Frequently check for traffic from rear, especially during turns. SAFETY DECALS 1. KEEP SAFETY DECALS CLEAN. 2. REPLACE missing or unreadable decals. New decals are available from your Summers dealer by ordering correct part number (PN) located on the decal. DECALS AND THEIR LOCATIONS 1.
  • Page 9 SECTION 1 - SAFETY 3. PN 8Z0202 – DECAL FOR COMPANY IDENTIFICATION ® 4. PN 8Z0276 – DECAL FOR GENERAL CAUTION 5. PN 8Z0340 – DECAL FOR REPHASING CYLINDERS...
  • Page 10 SECTION 1 - SAFETY 6. PN 8Z0342 – DECAL FOR INSTALLING CYLINDER LOCKS 7. PN 8Z0344 – DECAL FOR STAYING CLEAR OF WINGS 8. PN 8Z0346 – DECAL FOR ELECTROCUTION DANGER 9. PN 8Z0348 – DECAL FOR GAUGE WHEEL DEPTH 10.
  • Page 11 8Z2360 - 32’-40’ DISKCHISEL SAFETY LIGHT OPERATION The Summers Safety Light Kit is equipped with a 7 pin connector which meets SAE J560 specifica- tion. To protect 7 pin connector, store in dust cap (8K8067) when not attached to towing vehicle.
