Page 1 SINCE MACHINE DOES NOT COME READ & UNDERSTAND OPERATOR’S “FIELD READY” FROM FACTORY. MANUAL BEFORE USING MACHINE. See www.summersmfg.com for latest version of all Summers Operator’s Manuals. SUMMERS MANUFACTURING CO., INC. WEB SITE: www.summersmfg.com DEVILS LAKE, NORTH DAKOTA 58301 (701) 662-5391 8Z1065 ©...
Page 2 36 months from the date of purchase by the end user from Summers’ dealer. Summers’ obligation is to replace free of charge any part of any product that Summers inspection shows to be defective excluding transportation charges to Devils Lake, ND and return and also excluding all transportation costs from Summers’...
Page 3 . A complete parts breakdown is provided in the Parts Section. Parts are referenced in each drawing with the Summers Manufacturing Part Number. Use this Part Number when ordering replacement parts from your Summers dealer. See back section of manual for description of each Part Number.
Page 4: Table Of Contents
TABLE OF CONTENTS SECTION 1 – SAFETY SAFETY ALERT SYMBOL & GENERAL SAFETY PRACTICES……………………………………………….……[1.1] SAFETY DURING TRANSPORT…………………………………………………………………………………...……[1.2] SAFETY DECALS……………………………………………………………………………………………………[1.2]-[1.6] SECTION 2 – ASSEMBLY FINAL ASSEMBLY OF SETUP MACHINE…………………………………………………………………….…[2.1]-[2.2] MOUNTED ATTACHMENT ASSEMBLY……………………………………………………………………..…..[2.3]-[2.9] SECTION 3 – OPERATION, MAINTENANCE AND SPECIFICATIONS CONNECTING TO THE TRACTOR……………………………………………………………………………………..[3.1] PREPARING FOR FIELD OPERATION………………………………………………………………………………...[3.2] iPAD SETUP/iCONTROL APP…………………………………………………………………………………..…[3.3-3.10] CALIBRATION…………………………………………………………………………………………………...…[3.11-3.15]...
Page 5 ACRE METER………………………………………………………………………………………………….…………[4.43] HYDRAULIC LAYOUTS……………………………………………………………………………………..[4.44]-[4.60] HYDRAULIC CARTRIDGES………………………………………………………………………………………[4.61-4.63] WIRE HARNESSES…………………………………………………………………………………………….….[4.64-4.68] PART NUMBERS & DESCRIPTIONS…………………………………………………………………………...[4.69-4.75]...
Page 6 THIS PAGE LEFT INTENTIONALLY BLANK...
Page 7: Section 1 - Safety
SECTION 1 - SAFETY SAFETY-ALERT SYMBOL This symbol is used to denote possible danger and Care should be taken to prevent bodily injury. This symbol means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Definition of each Signal Word used in conjunction with the Safety-Alert symbol. Indicates an imminently hazardous situation which, if not DANGER avoided, will result in death or serious injury.
Page 8: Safety During Transport
5. FREQUENTLY check for traffic from rear, especially during turns. SAFETY DECALS 1. Keep safety decals clean. 2. Replace missing or unreadable decals. New decals are available from your Summers dealer by ordering correct part number (PN) located on decal. 3. Locations shown in Parts section.
Page 9 SECTION 1 - SAFETY 3. DISCONNECTING IMPLEMENT WARNING DECAL (PN 8Z0099) 4. REAR JACK DECAL (PN 8Z0102) 5. GENERAL CAUTION DECAL (PN 8Z0276)
Page 10 SECTION 1 - SAFETY 6. REPHASING CYLINDERS DECAL (PN 8Z0340) 7. INSTALLING CYLINDER LOCKS DECAL (PN 8Z0342) 8. STAYING CLEAR OF WINGS DECAL (PN 8Z0344)
Page 11 SECTION 1 - SAFETY 9. ROLLING ATTACHMENT DANGER DECAL (PN 8Z0345) ELECTROCUTION DANGER DECAL (PN 8Z0346) AMBER REFLECTOR (PN 8Z0800)
Page 12 RED-ORANGE REFLECTOR (8Z0805) RED REFLECTOR (PN 8Z0810) SAFETY LIGHT OPERATION The Summers Safety Light Kit is equipped with a 7-pin connector which meets SAE J560 specification. To protect 7-pin connector, store in dust cap (PN 8K8067) when not attached to towing vehicle.
Page 13: Section 2 - Assembly
SECTION 2 - ASSEMBLY The Summers VRT Renegade™ is shipped in 2 ways: Completely assembled, and partially assembled. If your machine is completely assembled, this section does not apply. If your machine is partially assembled, this section will show how to finish assembly (attach hitch and mounted attachments).
Page 14 SECTION 2 - ASSEMBLY...
Page 15 SECTION 2 - ASSEMBLY...
Page 16 SECTION 2 - ASSEMBLY...
Page 17 SECTION 2 - ASSEMBLY...
Page 18 SECTION 2 - ASSEMBLY...
Page 19 SECTION 2 - ASSEMBLY...
Page 20 SECTION 2 - ASSEMBLY...
Page 21 SECTION 2 - ASSEMBLY...
Page 22: Section 3 - Operation, Maintenance And Specifications
CONNECTING TO THE TRACTOR ELECTRICAL HOOKUP The Summers VRT Renegade™ is equipped The Summers Safety Light Kit is equipped with with and Articulating Ball hitch. This hitch is a 7 pin connector which meets SAE J560 designed to eliminate “slop” between the specification.
Page 23 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS BEFORE INITIAL OPERATION Remove the shipping locks from the center section Rolling Baskets, shown below. Cylinder Stops Remove rear jack and place into storage location. Failure to remove shipping locks may result in damage to the machine.
Page 24: Ipad Setup/Icontrol App
VRT Rengade’s WIFI network. With power supplied to the machine (tractor key in “On” or “Accessory” position) connect the IPad to the VRT Renegade’s WIFI network. The network name will be the same as the serial number printed on the Gateway 300, in this example “summers-S00062”.
Page 25 LED will change to a solid green necessary to temporarily increase the Wing light. Any other colors or blinking sequences Downpressure in order to unfold the wings. indicate an error. Please contact Summers See the “WING PRESSURE” section for more Service Dept. for assistance. information.
Page 26 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS...
Page 27 REPHASING SEQUENCE SELECTING BLADE TYPE It is recommended to run a Rephasing The VRT Renegade is designed to be able to Sequence at the start of, and occasionally operate with different blade types. If the throughout the day. To conduct a machine...
Page 28 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS HITCH ADJUSTMENTS To make adjustments to the Gauge Wheels, tap the “Gauge Wheels” button at the bottom of the To make adjustments to the Hydraulic Hitch, tap Home Screen.
Page 29 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS If no Wing Downpressure is desired, the operator may place the tractor hydraulic remote into “Float”. Important: The wing circuit must be run in either constant flow or float. Failure to do so may result in damage to the machine.
Page 30 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS Once the machine has been configured to achieve satisfactory results, a preset can be created by tapping the “Add +” button at the top of the Home Screen. A custom name can then be input for the preset.
Page 31 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS To activate Lockout Mode, tap the Lockout button TRANSPORT MODE at the top of the screen. To transition to the Transport Mode, tap the “Transport” button at the top of the Home Screen and follow the on-screen instructions.
Page 32: Calibration
SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS CALIBRATION SEQUENCE Upon entering Calibration, the user must perform certain actions, in a certain sequence, as instructed by the IControl™ App. This section will describe, in detail, the actions to be performed, as well as the automated movements the machine will make during the Calibration process.
Page 33 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS CALIBRATION SEQUENCE **USER INPUT** Fully extend depth control cylinders The remainder of the calibration sequence is controlled by the IControl™ system. Before beginning, ensure the AUXILIARY SCV is detented in the extend position. There is a check valve in the hydraulic circuit, allowing flow in only one direction.
Page 34 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS CALIBRATION SEQUENCE Hitch cylinders will fully retract, pitching machine forward. Hitch cylinders will fully extend, pitching machine rearward. Hitch cylinders will go to a mid-stroke position, leveling machine. 3.13...
Page 35 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS CALIBRATION SEQUENCE Front blade cylinders will fully extend, moving blades to maximum angle. Front blade cylinders will fully retract, moving blades to straight. Rear blade cylinders will fully retract, moving blades to straight. 3.14...
Page 36 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS CALIBRATION SEQUENCE Rear blade cylinders will fully extend, moving blades to maximum angle. Gauge wheel cylinders will fully extend, lowering wheels. Gauge wheel cylinders will fully retract, raising wheels. 3.15...
Page 37 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS FIELD OPERATION IMPORTANT -Ensure Wing and Auxiliary circuit SCVs are in constant flow. *NOTE: Optionally, Wing circuit SCV can be run in Float -Never turn on headlands with machine in the ground. -Operating the machine in hard or frozen soil conditions can have a negative impact on machine performance and may lead to damage to the trip mechanism.
Page 38: Storage
Inspect machine for damaged or worn parts, Use a safety chain between tractor drawbar and cracked or broken blades, and loose bolts. VRT Renegade™ hitch when transporting on public roads. Wheel bearings should be inspected seasonally. Check wheel bolts/nuts after first 20 miles of road It is recommended to store machine unfolded, with transport and every 60 miles thereafter.
Page 39: Maintenance
SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS MAINTENANCE Every 40 hours: Grease articulating ball hitch. Seasonally: Grease Fold Cylinder Pivot. Inspect and re-pack Wheel Bearings. Check Wheel Bolt/Nut torque. Tire Inflation: Recommended inflation pressures in chart below. Wheel Bolt/Nut Torque Load 614 - 6 BOLT 8K1100...
Page 40: Troubleshooting
SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS TROUBLESHOOTING For issues not addressed/remedied by this guide, please contact Summers Service Dept. PROBLEM PROBABLE CAUSE CORRECTION A. ISOBUS connection not Check connection seated properly iPad will not Check fuse or power source connect to Wi-Fi –...
Page 41 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS To move the machine to the right, increase front angle or A. Blade angle decrease rear. To move VRT Renegade™ is not running machine to the left, decrease straight or is “dog front angle or increase rear.
Page 42 SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS Turn the tractor off Unplug the ISOBUS connection iPad isn’t Close app responding or is A. Communication error Double click on iPad home locked up button and “swipe” off each app Re-open app Go to “settings”...
Page 43: Sensor Replacement
SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS SECTION 3 – OPERATION, MAINTENANCE & SPECIFICATIONS SECTION 4– PARTS SENSOR REPLACEMENT BLADE ANGLE SENSOR MAIN LIFT, GAUGE WHEEL, HITCH SENSOR NOTE ORIENTATION OF SENSOR CONNECTOR AND LEVER DIRECTION 3.22...
Page 44 SECTION 4 - PARTS...
Page 45 SECTION 4 - PARTS ITEM DESCRIPTION 8B1270B OSC AXLE SPNDLE HLDR 2.5" 8B2515P FRAME WING RNGD 25'-30' R-PTD 8B2540 LIFTARM OSC AXL-RNGD 8B2542L CYL ATTCH 285/70R19.5 W/BUSH-L 8B2542R CYL ATTCH 285/70R19.5 W/BUSH-R 8D9108 ROLL PIN 1/4 X 2" YLW ZNC 8K1105 HUB&AXLE ASSY HD812(2.5"RCVR) 8K7410...
Page 46 SECTION 4 - PARTS...
Page 47 SECTION 4 - PARTS ITEM DESCRIPTION 8B0030 CONTROLLER MNT PANEL 8B1215 WING LOCK TAB VRT 8B1217 WING LOCK TAB SPCR 8B2532 WING REST TUBE 25'-30' 8B2536 SPACER .76"ID X 4" 8B2537 ANTENNA MNT 8B2538 HYD VLV BLOCK MOUNT 8B2558 CYL ATTCH WINFOLD 25'-30' 8B2560 TRANSREST MNT PLATE 8D8523 JACK 8000# DROPLEG 5/8X4.25PIN 8D9108 ROLL PIN 1/4 X 2"...
Page 48 SECTION 4 - PARTS...
Page 49 SECTION 4 - PARTS ITEM DESCRIPTION 8B1270B OSC AXLE SPNDLE HLDR 2.5" 8B2025 PIN 1-1/2" X 5.375" YZ 8B2495P ATTCHMNT ARM MNT EXT-PTD 8B2525P FRAME WING RNGD 25'-30' L-PTD 8B2527P FRAME WING RNGD 25'-30' R-PTD 8B2540 LIFTARM OSC AXL-RNGD 8B2542L CYL ATTCH 285/70R19.5 W/BUSH-L 8B2542R CYL ATTCH 285/70R19.5 W/BUSH-R 8B2550...
Page 50 SECTION 4 - PARTS...
Page 51 SECTION 4 - PARTS SECTION 4 - PARTS ITEM DESCRIPTION 8B2505P HITCH VRT RNGD 25'-30'-PTD 8D0760 HITCH ARTIC. BALL CAT 4 8D2470 SAFETY CHAIN 7/16" X 5' 8D8523 JACK 8000# DROPLEG 5/8X4.25PIN 8K8067 DUST CAP FOR 7PIN CONNECT00- 8N0700 HYD HOSE ARM 8N0703 HYD HOSE TIP HOLDER-3 PAIR 8P3910...
Page 52 SECTION 4 - PARTS...
Page 53 SECTION 4 - PARTS ITEM DESCRIPTION 8B0037 ROTARY SENSOR 8B0038 WIFI ANTENNA 8B0039 GW300 8B0040 IO400 8B2835 SENSOR LINK-GAGEWHL 8B2836 SENSOR LINK MNT-GAGEWHL 8B2840 SENESOR LINK-HITCH ANGLE 8B2841 SENSOR LINK MNT-HITCH ANGLE 8B2847 SENSOR LINK-DEPTH CNTRL 25-30' 8B2850 SENSOR LINK-UNIVERSAL 8B2855 ROTARY SENSOR MNT 8B2860...
Page 54 SECTION 4 - PARTS 4.11...
Page 55 SECTION 4 - PARTS ITEM DESCRIPTION 8K8005 TUBE LGHT BRKT SHRT 1.5SQ PNTD 8K8020 MOUNTNG BRCKT LIGHT 00- 8K8090B LIGHT LED AMBER 2WR DTSCH 12- 8K8095B LIGHT LED RED 3WIRE DTSCH 12- 8L0258 U-BOLT 5/16 X 1-1/2 X 2-1/2"SQ 8S1120 SIGN SLOW MOVING VEHICLE(SMV) 8S1124 MOUNTING SOCKET SMV SIGN ZDI...
Page 56 SECTION 4 - PARTS 4.13...
Page 57 SECTION 4 - PARTS ITEM DESCRIPTION 8B2510P FRAME CENTER RNGD 35'-40'-PTD 8B2540 LIFTARM OSC AXL-RNGD 8B2541L CYL ATTCH-385/65R22.5-L 8B2541R CYL ATTCH-385/65R22.5-R 8D9108 ROLL PIN 1/4 X 2" YLW ZNC 8J4167 OSC AXLE SPNDLE HLDR 3.375" 8J4168B OSC AXLE SPNDLE HLDR MNT 8K1109 SPINDLE W/H1010 15K 8K7216...
Page 58 SECTION 4 - PARTS 4.15...
Page 59 SECTION 4 - PARTS ITEM DESCRIPTION 8A1155 U-BOLT 3/8 X 6-1/16 X 5" SQ 8B0030 CONTROLLER MNT PANEL 8B1215 WING LOCK TAB VRT 8B1217 WING LOCK TAB SPCR 8B2530 WING REST TUBE 35'-40' 8B2536 SPACER .76"ID X 4" 8B2537 ANTENNA MNT 8B2538 HYD VLV BLOCK MOUNT 8B2555B CYL ATTCH WINGFOLD 35'-40'...
Page 60 SECTION 4 - PARTS 4.17...
Page 61 SECTION 4 - PARTS ITEM DESCRIPTION 8B2500P HITCH VRT RNGD 35'-40'-PNTD 8D0770 HITCH ARTIC. BALL CAT 5 8D0771 BUSHING 2"ID FOR 8D0770 8D2480 SAFETY CHAIN 61000# 5/8" X 66" 8D8523 JACK 8000# DROPLEG 5/8X4.25PIN 8K8067 DUST CAP FOR 7PIN CONNECT00- 8N0200 BULKHEAD PLATE - HITCH 8N0700...
Page 62 SECTION 4 - PARTS 4.19...
Page 63 SECTION 4 - PARTS ITEM DESCRIPTION ITEM DESCRIPTION 8B1270B OSC AXLE SPNDLE HLDR 2.5" 8X0242 NUT 1/2"-13NC NY-LOCK GR2 YZ 8B2025 PIN 1-1/2" X 5.375" YZ 8X0253 NUT 5/8"-11NC NY-LOCK GR2 YZ 8B2495P ATTCHMNT ARM MNT EXT-PTD 8X0261 NUT 3/4"-10NC NY-LOCK GR2 YZ 8B2520P FRAME WING RNGD 35'-40' L-PTD 8X0265 NUT 3/4"-10NC CNTRLOCK GR2 YZ...
Page 64 SECTION 4 - PARTS 4.21...
Page 65 SECTION 4 - PARTS ITEM DESCRIPTION 8B0037 ROTARY SENSOR 8B0038 WIFI ANTENNA 8B0039 GW300 8B0040 IO400 8B2831 SENSOR LINK-BLADE ANGLE-FLAT 8B2835 SENSOR LINK-GAGEWHL 8B2836 SENSOR LINK MNT-GAGEWHL 8B2845 SENSOR LINK-DEPTH CNTRL 8B2850 SENSOR LINK-UNIVERSAL 8B2855 ROTARY SENSOR MNT 8B2860 SLEEVE #10 IDX3/8"ODX.40" 8B2865 STANDOFF .56"IDX1"ODX4.85"...
Page 66 SECTION 4 - PARTS 4.23...
Page 67 SECTION 4 - PARTS ITEM DESCRIPTION 8K8005 TUBE LGHT BRKT SHRT 1.5SQ PNTD 8K8020 MOUNTNG BRCKT LIGHT 00- 8K8090B LIGHT LED AMBER 2WR DTSCH 12- 8K8095B LIGHT LED RED 3WIRE DTSCH 12- 8L0258 U-BOLT 5/16 X 1-1/2 X 2-1/2"SQ 8S1120 SIGN SLOW MOVING VEHICLE(SMV) 8S1124 MOUNTING SOCKET SMV SIGN ZDI...
Page 68 SECTION 4 - PARTS 4.25...
Page 69 8Z0075 TRANSPORT LOCK DECAL 8Z0087 DECAL"WARNING"PINCH POINT03- 8Z0099 WARNING JACK DECAL 8Z0100 MADE IN THE USA DECAL 8Z0202 3.5" SUMMERS DECAL 8Z0206 7.5" SUMMERS DECAL 8Z0276 GENERAL MACHINE CAUTION DECAL 8Z0340 REPHASING CYLINDERS DECAL 8Z0342 INSTALL CYL LOCKS DECAL 8Z0344...
Page 70 SECTION 4 - PARTS 4.27...
Page 71 SECTION 4 - PARTS ITEM DESCRIPTION ITEM DESCRIPTION 8B0015 TRIP BUMP STOP 8X0122 BOLT 3/4-10NC X 4-1/2" GR5 YZ NUT 3/4"-10NC CNTRLOCK GR2 8B0062B HOUSING W/SHAFT-DISK TRIP 8X0265 8B0065 ARM - DISK TRIP 8X0282 NUT 1"-14TPI TOPLOCK GR B Z 8B0069 PRELOAD PIVOT W/BUSH 8X0306...
Page 72 SECTION 4 - PARTS 4.29...
Page 73 SECTION 4 - PARTS ITEM DESCRIPTION 8B2535 DEPTH CNTRL VLV MNT 8B2538 HYD VLV BLOCK MOUNT 8B9110 SUB-ASSY HYD BLOCKS 8J5500 9/16"-18 ORB X #6 JIC(M) STR 8J5510 3/4"-16 ORB X #6 JIC(M) STR 8J5540 7/8"-14 ORB X #10 JIC(M) STR 8J5550 1-1/16"...
Page 74 SECTION 4 - PARTS 4.31...
Page 75 SECTION 4 - PARTS ITEM DESCRIPTION 8H1180S HARROW TOOTH 1/2 X 20" M104/SH 8HD0080 PIPE CLAMP 2-1/2"ID PLATED ZDI 8HD0150 8HD0160 COMPRESSION SPRING 8HD0200 U-BOLT 1/2 X 2-3/8 X 3-9/16" RND 8HD5052 1ST PIPE W/LVR 6' 3OR4BR 8HD5072 1ST PIPE W/LVR 8' 104/6 3OR4BR 8HD5082 1ST PIPE W/LVR10' 104/6 3OR4BR 8HD5054...
Page 76 SECTION 4 - PARTS 4.33...
Page 77 SECTION 4 - PARTS ITEM DESCRIPTION 8H2601B RLLNG BSKT ENDPLATE 4SCRPR 8H2634 RLLNG BSKT 4' REEL ONLY 8H2636 RLLNG BSKT 6' REEL ONLY 8H2660B RLLING BSKT SCRAPR MNT 8H2664 4' BSKT SCRAPER (40.5") 8H2666 6' BSKT SCRAPER (63.5") 8H2703 BEARING 1-1/4" SQ FLNG4BLT 8H2706 TUBE SQ 3 X 4T- 70"...
Page 78 SECTION 4 - PARTS 4.35...
Page 79 ITEM DESCRIPTION 8B2175 HYD CYL 2.0 X 1.75" HYD BSKT 8C1755 U-BOLT 3/4 X 6-1/16 X 6" SQ 8H1290 BOLT-SPRINGROD 7/8" X 29" 8H1295 SPRING-COMP - 1.71"ODX7"X.262" 8H2005 CYLINDER SPACER 8H3000 MNT HEAD HRRW/HYD BSKT 8H3010 ARM, HRRW- 32" 8H3020 ARM, BSKT- 57"...
Page 80 SECTION 4 - PARTS 4.37...
Page 81 SECTION 4 - PARTS ITEM DESCRIPTION 8B0050 SPRING URETHANE 2"ODX4" 8B0120 DEFLECTOR TRIP HOUSING 8B0125 ARM - DEFLECTOR TRIP 8B3990 DUST CAP GUARD 8B4000/8B4001 8B3990B DUST CAP GUARD 8B4000B/8B4001B 8B4001 SNGL TILLAGE HUB MAINTFREE 8B4001B SNGL TILLAGE HUB 8B4019 NUT NYLOCK FLNG 1/2"-20 8T3300 PIVOT BOLT CHSLTRP&WNGLFT YZ 8X0113...
Page 82 SECTION 4 - PARTS SECTION 4 - PARTS 4.32 4.39...
Page 83 SECTION 4 - PARTS 8K1100 ITEM DESCRIPTION 8D5217 BEARING IN 517 OUT 614 & 618 8D5312 NUT 1"-14NF HEX SLOT GR2 PLN 8D5319 WASHER 1" AXLE 8D5332 RACE H517 & H614 8R6901 AXLE H614 STR 2"CR X 10" 8R6911 HUB H614 W/CUPS&ZRK 6 BLT GBGI 8R6913 HUB CAP H614 &...
Page 84 SECTION 4 - PARTS 4.41...
Page 85 SECTION 4 - PARTS 8K1106 ITEM DESCRIPTION 8D5314 NUT 1-1/4"-12 HEX SLOT GR2 PLN 8K7123 NUT WHEEL BOLT 5/8-18UNF 97- 8K7340 HUB HD817 W/CUPS&SRK 8BLT3LIP 8K7341 HUB CAP HD817 8K7342 BEARING INNER HD817 8K7343 BEARING OUTER HD817 8K7344 SEAL 3"ID HD817 SE42 8K7346 RACE INNER HD817 8K7347...
Page 86 SECTION 4 - PARTS 4.43...
Page 87 SECTION 4 - PARTS 4.44...
Page 88 SECTION 4 - PARTS SECTION 4 - PARTS 4.45 4.45...
Page 89 SECTION 4 - PARTS 4.46...
Page 90 SECTION 4 - PARTS 4.47...
Page 91 SECTION 4 - PARTS 4.48...
Page 92 SECTION 4 - PARTS 4.49...
Page 93 SECTION 4 - PARTS 4.50...
Page 94 SECTION 4 - PARTS 4.51...
Page 95 SECTION 4 - PARTS 4.52...
Page 96 SECTION 4 - PARTS 4.53...
Page 97 SECTION 4 - PARTS 4.54...
Page 98 SECTION 4 - PARTS 4.55...
Page 99 SECTION 4 - PARTS 4.56...
Page 100 SECTION 4 - PARTS 4.57...
Page 101 SECTION 4 - PARTS 4.58...
Page 102 SECTION 4 - PARTS 4.59...
Page 103 SECTION 4 - PARTS 4.60...
Page 104 SECTION 4 - PARTS 4.61...
Page 105 SECTION 4 - PARTS 4.62...
Page 106 SECTION 4 - PARTS 4.63...
Page 107 SECTION 4 - PARTS 4.64...
Page 108 SECTION 4 - PARTS 4.65...
Page 109 SECTION 4 - PARTS 4.66...
Page 110 SECTION 4 - PARTS 4.67...
Page 111: Deflector Arm
SECTION 4 - PARTS SECTION 4 - PARTS 8A1155 U-BOLT 3/8 X 6-1/16 X 5" SQ 8B2500P HITCH VRT RNGD 35'-40'-PNTD 8B0005 GROMMET 1.75"ODX1.375"ID 8B2505P HITCH VRT RNGD 25'-30'-PTD 8B0015 TRIP BUMP STOP 8B2510P FRAME CENTER RNGD 35'-40'-PTD 8B0030 CONTROLLER MNT PANEL 8B2515P FRAME WING RNGD 25'-30' R-PTD 8B0037...
Page 112 SECTION 4 - PARTS 8B2841 SENSOR LINK MNT-HITCH ANGLE 8D5244 NUT FLANGE SLOTTED 1"-14 8B2845 SENSOR LINK-DEPTH CNTRL 8D5246 V-SEAL GBGI TILL HUB 8B2847 SENSOR LINK-DEPTH CNTRL 25-30' 8D5247 STUD 1/2"-NF GBGI TILL HUB 8B2850 SENSOR LINK-UNIVERSAL 8D5312 NUT 1"-14NF HEX SLOT GR2 PLN 8B2855 ROTARY SENSOR MNT 8D5314...
Page 113 SECTION 4 - PARTS 8HD0160 COMPRESSION SPRING 8J6000 9/16"-18 ORB X #6 JIC(M)90*ADP 8HD0200 U-BOLT 1/2 X 2-3/8 X 3-9/16" RND 8J6010 3/4"-16 ORB X #6 JIC(M)90*ADP 8HD5052 1ST PIPE W/LVR 6' 3OR4BR 8J6020 3/4"-16 ORB X #10 JIC(M)90*ADP 8HD5054 2ND PIPE W/LVR 6' 3OR4BR 8J6030 7/8"-14 ORB X #10 JIC(M)90*ADP...
Page 114 SECTION 4 - PARTS 8K7343 BEARING OUTER HD817 8N3124 3/8X 124"HYD HOSE #6FJX3000PSI 8K7344 SEAL 3"ID HD817 SE42 8N3135 3/8X 135"HYD HOSE #6FJX3000PSI 8K7346 RACE INNER HD817 8N3136 3/8X 136"HYD HOSE #6FJX3000PSI 8K7347 RACE GBGI & OUTR 817 8N3150 3/8X 150"HYD HOSE #6FJX3000PSI 8K7349 AXLE HD817X 15.25"...
Page 115 SECTION 4 - PARTS SECTION 4 - PARTS 8R6922 SEAL ASSY GBGI H614 HUB 00- 8X0066 BOLT 1/2-13NC X 1-3/4" GR5 ZDI 8R6925 RACE INNER H614 8X0066 BOLT 1/2-13NC X 1-3/4" GR5 YZ 8S0358 U-BOLT 5/8 X 3-1/16 X 4-1/2" SQ. 8X0067 BOLT 1/2-13NC X 2-1/4"...
Page 116 8XM0110 SCREW,SS - BTTN HEAD M6 X 10MM 8XM0200 NUT,SS - NY-LOCK M5 8X0283 NUT 1-1/4"-7NC JAM GR2 YZ 8X0300 LOCKWASHER 5/16" YLW ZNC 8Y2250 KIT DECAL - VRT RENEGADE 8X0303 LOCKWASHER 1/2" YLW ZNC 8Z0046 PATENT PENDING DECAL 8X0304 LOCKWASHER 5/8" YLW ZNC 8Z0046 DECAL PATENT PENDING 1.25X3"...
Page 117 SECTION 4 - PARTS 8Z0202 3.5" SUMMERS DECAL 8Z0202 DECAL 3.5" SUMMERS 14- 8Z0206 7.5" SUMMERS DECAL 8Z0206 7.5" SUMMERS DECAL 14-14 8Z0276 GENERAL MACHINE CAUTION DECAL 8Z0276 DECAL GENERAL CAUTION 91- 8Z0340 REPHASING CYLINDERS DECAL 8Z0340 DECAL REPHASING CYLINDERS...
Page 118 2004 - A 124 ft. x 310 ft. addition is added onto the current Devils Lake plant. 2005 - The Summers Superroller is added to the “Field Tested Tough” product line. Additional sizes of 56’, 58’ and 60’ are added to the Superchisel line.
