1.4

Card Formats

The following card formats are supported:
•
•
•
•
•
•
•
•
•
•
•
•
1.5

Installer Responsibilities

The installation and setup must be done by a qualified technician. The technician
is responsible for installing all of the system components, connecting all of the
input and output wiring for the appropriate door entry systems, and ensuring that
the wiring adheres to the requirements of the system for proper operation using
the Configurator software.
1.6

Typical Wiring Diagram

1.
2.
3.
4.
TX3-CX-1 Installation Manual
Version 1.1
LT-6618 Copyright 2019
26-bit Wiegand SIA
32-bit CSN
34-bit Awid
35-bit HID corporate 1000
35-bit Indala
36-bit HID Simplex
36-bit Keyscan C15001
37-bit Cansec
37-bit HID 10304
37-bit Mircom
39-bit Kantech XSF
50-bit RBH
TX3-CX-1 Single Door Controller fits onto single gang electrical box
Electric Door Strike preferably with built-in door position switch
Door position switch
Power Supply with or without battery backup
Welcome
