7. While a second person holds the Console (23)
near the Upright (2), plug the Wire Harness (73)
and the Pulse Wires (84) into the receptacles (D)
on the Console.
The connectors on the Wire Harness (73) and
the Pulse Wires (84) should slide easily into
the receptacles (D) and snap into place. If a
connector does not slide easily into a receptacle,
turn the connector and try again. If you do not
connect the connectors properly, the Console
(23) may become damaged when you use the
elliptical.
8. Insert the excess wire into the Upright (2).
Tip: Avoid pinching the wires. Attach the
Console (23) to the Upright (2) with four
M4 x 16mm Screws (52); start all the Screws,
and then tighten them.
7
23
8
23
Avoid pinching
the wires
10
D
73, 84
2
2
52
