6. Data Memory

This device automatically stores up to 99 measurement values.

Viewing the stored values

Press the M-button 9 briefly, when the device is switched on.
The display first shows «M»
device then switches to the last stored value.
Press the M-button again to exit the memory mode. Pressing the
«+» 11 or the «-» 10 button repeatedly enables you to move from
one stored value to another.

Memory full

Please note that the maximum memory capacity is 99
values. When the 99 memoryis full, the oldest value
is automatically overwritten with the 100th value.
Values should be evaluated by a doctor before the
memory capacity is reached – otherwise data will be lost.
Clearing all values
If you are sure that you want to permanently remove all stored
values, hold down the M-button
release the button.
Press the M-button while «CL» is flashing to permanently clear
all values.
Cancel deletion: press START/STOP button
«CL» is flashing.
Individual values cannot be cleared.

7. Battery Indicator and Battery change

Low battery

When the batteries are approximately ¾ empty the battery
symbol will flash as soon as the device is switched on (partly
17
filled battery displayed). Although the device will continue to
measure reliably, you should obtain replacement batteries.
aponorm ® Basis Plus
and then an average value. The
19
9 until «CL» appears and then
1 while
Flat battery – replacement
When the batteries are flat, the battery symbol
soon as the device is switched on (flat battery displayed). You
cannot take any further measurements and must replace the
batteries.
1. Open the battery compartment
device.
2. Replace the batteries – ensure correct polarity as shown by
the symbols in the compartment.
3. To set date and time, follow the procedure described in
«Section 2.».
The memory retains all values although date and time
must be reset – the year number therefore flashes auto-
matically after the batteries are replaced.

Which batteries and which procedure?

Use 4 new, long-life 1.5 V, size AAA alkaline batteries.
Use only batteries of one brand at a time.
Do not use batteries beyond their date of expiry.
Remove batteries if the device is not going to be used for
a prolonged period.

Using rechargeable batteries

You can also operate this device using rechargeable batteries.
Only use «NiMH» type reusable batteries.
Batteries must be removed and recharged when the flat
battery symbol appears. They should not remain inside the
device as they may become damaged (total discharge as a
result of low use of the device, even when switched off).
Always remove the rechargeable batteries if you do not
intend to use the device for a week or more.
Batteries cannot be charged in the blood pressure monitor.
Recharge batteries in an external charger and observe the
information regarding charging, care and durability.
17 will flash as
5 on the bottom of the
