Dräger Savina 300 Quick Start Manual

Dräger Savina 300/Classic/Select
®
Disassembly/Assembly
Disassembly/Assembly
Open the flap by lifting the
lower edge upwards.
Close the flap.
Disassembly/Assembly
Turn the locking ring as far as
possible to the left.
Turn the locking ring as far
as possible to the right
until it clicks into place.
Remove the diaphragm.
Fit the diaphragm onto the edge
of the expiratory valve housing.
Flow Sensor
Pull the flow sensor as far
as it will go to the left.
Push the flow sensor to
the right into the socket.
Expiratory Valve
Remove the expiratory valve
from the fitting.
Turn the locking ring as far as
possible to the left, push the
expiratory valve into the fitting.
Remove and empty the water
trap container.
Fit the water trap container.
Dräger Savina ® 300 Dräger Savina
Remove the flow sensor
from the socket.
Pull the sensor sleeve from
the expiratory valve.
Fit the flow sensor sleeve
on the expiratory valve.
® 300 Classic Dräger Savina ® 300 Select
Fit the flow sensor
into the socket.
