MC100
Mobile programmable gateway
11.6.3
Port
+A1
-A1
+A2
-A2
The input current at
Note: The applied DC voltage must not exceed 10V.
Function: Reading the voltage inputs (v1.0.4 and older)
Port
+A1,-A1
+A2,-A2
Example:
Command:
Response:
Function: Reading the voltage inputs (v1.0.5 and later)
Port
+A1,-A1
+A2,-A2
Example:
Command:
Response:
Note:
Formula:
Example:
11.6.4
The analog current inputs of the MC100 SensT2 have two operating modes.
MC Technologies GmbH, Kabelkamp 2, 30179 Hannover, Germany
Tel: +49511 67 69 99-0, Fax: +49511 67 69 99-150, Website & Shop: www.mc-technologies.net, Email: info@mc-technologies.net
Voltage inputs 0 – 10V
Description
Positive connection Input 1
Negative connection Input 1
Positive connection Input 2
Negative connection Input 2
10V is approx. 2 mA
Parameter Read
Value x
Value x
Read voltage at ADC input +A1,-A1
cat /sys/senst2_ADC/voltage/volt0/value
e.g. 6400
Parameter Read
Value x
Value x
Read voltage at ADC input +A1,-A1
cat /sys/senst2_board/voltage_in1/value
e.g. 6400
Conversion to volts
Voltage in Volt = value / 1000
Value = 6400 corresponds to 6.4V

Current inputs 0 - 20mA

1. Supply of a current - current from the sensor - sensor with own power
supply
2. Low side shunt - with power supply for the sensor
Write
/sys/senst2_ADC/voltage/volt0/value
/sys/senst2_ADC/voltage/volt1/value
Write
/sys/senst2_board/voltage_in/1
/sys/senst2_board/voltage_in/2
Path
Path
