MC100
Mobile programmable gateway
Example:
Command:
Response:
11.5.3
Port
+A1
-A1
+A2
-A2
The input current at
Note: The applied DC voltage must not exceed 10V.
Function: Reading the voltage inputs (v1.0.4 or older)
Port
+A1,-A1
+A2,-A2
Example:
Command:
Response:
Function: Reading the voltage inputs (v1.0.5 or later)
Port
+A1,-A1
+A2,-A2
Example:
Command:
Response:
Note:
Formula:
Example:
11.5.4
MC Technologies GmbH, Kabelkamp 2, 30179 Hannover, Germany
Tel: +49511 67 69 99-0, Fax: +49511 67 69 99-150, Website & Shop: www.mc-technologies.net, Email: info@mc-technologies.net
Switch on output O1A,O1B
echo 1 > /sys/gpio_board/output/value
#
Voltage inputs 0 – 10V
Description
Positive connection Input 1
Negative connection Input 1
Positive connection Input 2
Negative connection Input 2
10V is approx. 2 mA
Parameter Read
Value x
Value x
Read voltage at ADC input +A1,-A1
cat /sys/gpio_board_ADC/voltage/volt0/value
e.g. 6400
Parameter Read
Value x
Value x
Read voltage at ADC input +A1,-A1
cat /sys/gpio_board/ voltage_in1/value
e.g. 6400
Converting to volts
Voltage in Volt = value / 1000
Value = 6400 corresponds to 6.4V

Current inputs 0 - 20mA

Write
/sys/gpio_board_ADC/voltage/volt0/value
/sys/gpio_board_ADC/voltage/volt1/value
Write
/sys/gpio_board/ voltage_in/1
/sys/gpio_board/ voltage_in/2
Path
Path
