MC100
Mobile programmable gateway
9.11 Node-RED Web Interface
Node-RED is a programming tool that allows hardware devices, APIs and online services to
be wired together. It is builds on Node.js, fully utilizing the advantages of its event-driven,
non-blocking model.
It offers a browser-based editor that enables to easily wire flows by using the wide range of
nodes in the palette.
If Node-RED is installed, you can reach the Node-RED web interface with the same IP
address as the standard web interface and the specification of the port (e.g. 1880)
Example with default address:
(Note: Using https:// will not work.)
9.11.1
Click on "System" in the left menu and then on "Startup".
Search for Initscript: "node-red" and Click the "Enable/Disable" button.
9.11.2
To install modules for Node-RED:
1. Open Node-RED web interface.
2. On the left upper corner, click on the 3 dash button.
3. Click on "Manage Palette".
4. In the "Manage Palette" interface, Click on install.
5. Type the modules name in "Search modules".
9.11.3
Select the node you want to add from the nodes list (i.e. Inject node, allow injecting
messages into a flow). Drag it into the workspace.
MC Technologies GmbH, Kabelkamp 2, 30179 Hannover, Germany
Tel: +49511 67 69 99-0, Fax: +49511 67 69 99-150, Website & Shop: www.mc-technologies.net, Email: info@mc-technologies.net
http://192.168.2.1:1880

Enable the Node-Red installed in MC100:

Install extra modules:

Add a node
