- Page 1 Quick Start Guide Model RidgeWave® BEC 7000 R25 Product: 4G LTE-A Pro Outdoor Router teamsupport@bectechnologies.net | +1 972-422-0877 www.bectechnologies.net...
- Page 2 RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router • PLEASE READ THE QUICK START GUIDE AND FOLLOW THE STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE. IF YOU NEED MORE INFORMATION ON THIS SOFTWARE CONFIGURATION, PLEASE REFER TO THE USER MANUAL.
-
Page 3: Hardware Overview
Insert the SIM card into the SIM slot. SIM / LED / Reset Press the reset button to reset device or restore to factory default settings Connect the supplied BEC PoE injector to the LAN/PoE port using an Ethernet cable. Gigabit LAN / PoE STATUS... -
Page 4: Mounting Kit Installation
RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router Mounting Kit Installation Mounting Kit includes: 1) Stainless Steel Bracket x 1 2) Hose Clamp x 2 M6x15 Screw x 4 3) M6x15 Screw x 4 4) M6 Washer x 4 Hose clamp 1”~3”... - Page 5 RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router Pole Mounting for Pole 1” ~ 3” (25.4 ~ 76.2mm) Use 1~3” hose clamps through Fix the stainless-steel bracket to the the stainless-steel bracket. pole by using the supplied stainless hose clamps (1” ~ 3”). Use a flat- head screwdriver to turn the head of the screw clockwise to tighten it.
- Page 6 RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router Proper Grounding to Complete the Installation Attach the grounding wire to the RidgeWave® BEC 7000 R25 and tighten the screw.
- Page 7 RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router Router Installation Instructions Power on your RidgeWave® BEC 7000 R25 Step 1: Assemble M25 cable gland Step 2: Unscrew the LAN (PoE) cap then insert an outdoor Ethernet cable (RJ-45) through material A-D, and then connect the RJ-45 Ethernet cable into the LAN (PoE) port.
- Page 8 Data+Power port. Connect another Ethernet cable (RJ-45) directly to the Data port and the other end of cable to a switch or broadband router. IMPORTANT: It is recommended to put the Gigabit PoE Injector on an UPS or Surge Protector. Use a grounding wire to ground your RidgeWave® BEC 7000 R25 is REQUIRED!
-
Page 9: Internet Connection Setting
RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router Internet Connection Setting 1. Set up your 4G LTE Internet Connection Step 1: Unscrew the cap of SIM card slot. Step 2: Slide the SIM card with the mental contacts (gold plate) facing down to the SIM slot then push it all the way in until you hear the clicking sound. - Page 10 RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router Step 4: Login to your RidgeWave® BEC 7000 R25 The default IP of the router is 192.168.1.254 with subnet 255.255.255.0. Make sure the attached PC to this router is in the same subnet and has an IP address in the range between 192.168.1.1 ~ 192.168.1.253.
-
Page 11: Troubleshooting
RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router Troubleshooting 1. None of the LEDs are on when you turn on the Router. Check the connection between the adapter and the router. If the error persists, you may have a hardware problem. In this case you should contact technical support. -
Page 12: Professional Installation Instructions
RidgeWave® BEC 7000 R25 4G LTE-A Pro Outdoor Router FCC Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
