PRESSURE INJURY PREVENTION
Product training:
Provizio
SEM Scanner
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Provizio SEM Scanner and is the answer not in the manual?

Questions and answers

Related Manuals for Arjo Provizio SEM Scanner

Summary of Contents for Arjo Provizio SEM Scanner

  • Page 1 PRESSURE INJURY PREVENTION Product training: Provizio SEM Scanner ®...

  • Page 2: Table Of Contents

    Summary Before you start Start-up Mode of operation Scan Reset Clean Data upload Charge & power down PROVIZIO SEM SCAN N ER • PRODUC T TR AIN ING...

  • Page 3: Before You Start

    Before you start Sensor Patient barcode scanner* Battery gauge Patient ID Status indicator SEM delta SEM value Action button (On device) Charging * Available in Provizio V2 PROVIZIO SEM SCAN N ER • PRODUC T TR AIN ING...

  • Page 4: Start-Up

    Splash Screen displays Installing the Sensor After approximately 4 seconds the Remove the Provizio SEM Scanner single-use sensor Press the Next Screen Button to continue, the Install Sensor Screen will display from its packaging and place onto the sensor head.

  • Page 5: Mode Of Operation

    Pressing the Barcode Button will implement full data upload. Use this mode if the patient has a bar coded wrist band and the Provizio SEM Scanner Gateway Dashboard is installed on your WiFi network. Press the Barcode Button on the...
  • Page 6 Mode of operation Select one of the four options available (A to D) Option B: Manual Charting Button Pressing the Manual Charting Button will implement the manual operation mode. For when the patient does not have a bar coded wrist band, or you do not have the Gateway Dashboard installed on your WiFi network Option C: Manual Patient ID Button...

  • Page 7: Scan

    Scan How to scan Select the body area you Ensure that any surface moisture or matter is removed from the area on the wish to scan by pressing skin being assessed the Select Button Apply the sensor head flat against the patient’s skin in the area to be scanned with sufficient pressure until the scan is triggered...
  • Page 8 Where to scan Sacrum Readings: Complete six (6) Provizio SEM Scanner readings at the positions shown in the figure Reading is taken just above the gluteal cleft, around S3 of the sacral bone. Always start the scanning of the sacrum with reading as indicated in the figure.
  • Page 9 (one heel at a time) as shown in the 4 figures. Avoid placement of the Provizio SEM Scanner on hard or broken skin of the heel (such as a calloused heel). The order of the scan in each heel is not relevant, but at least 3 scans need to be taken for a delta to show.

  • Page 10: Reset

    Reset Once all body locations are complete: Press the Home Button to return to the Install Sensor Screen If Gateway is installed, the scanner will save and store all readings taken in encrypted form until uploaded on the Gateway Dashboard If using the Manual Charting Option the SEM readings are deleted once the scanning session is left Remove the sensor by gently pulling away from the sensor...
  • Page 11 Provizio SEM Scanner FH ® Note: When wiping the Provizio SEM Scanner with the wipe, you are applying the cleaning and disinfecting agent onto the scanner. Before starting the disinfection, first clean the scanner as described above. Dispense fresh CaviWipe™ towelette wipe from the dispenser and verify the wipe is moist.

  • Page 12: Data Upload

    Data upload Gateway installed To upload the readings taken: Place the Provizio SEM Scanner into the Charging Hub, the scanner initiates wireless communications and connects to the Gateway Dashboard All stored, encrypted data sessions are uploaded to the Gateway Dashboard and deleted from the scanner.

  • Page 13: Charge & Power Down

    Charge & power down To charge, place the scanner in the Charging Hub The battery time • The Charging Hub light will start for the Provizio flashing green SEM Scanner is • Whilst the scanner is in the Charging approximately 3 Hub, the touchscreen is disabled hours of active scanning.
  • Page 14 Instruction For Use online document by scanning the QR code The Provizio® SEM scanner is manufactured by Bruin Biometrics LLC and distributed under contract by Arjo AB. Copyright, trademarks and logos are the intellectual property of Bruin Biometrics LLC, this includes the following: Provizio SEM Scanner and SEM Scanner Bruin Biometrics LLCs copyright materials cannot be used or reproduced without Bruin Biometrics LLCs written consent.
