Mode of operation

Select one of the four options
available (A to D)
Option A: Barcode Button
Pressing the Barcode Button will implement full data
upload. Use this mode if the patient has a bar coded
wrist band and the Provizio SEM Scanner Gateway
Dashboard is installed on your WiFi network.
Press the Barcode Button on the
1
Barcode Scanning Screen
5
PROVIZIO SEM SCAN N ER • PRODUC T TR AIN ING
0 1 2 3 4
Position the scanner and use the green
2
light to aim the barcode reader at the
patient barcode.
5 6 7
Once the scanner has
identified the barcode, it will
emit a short audio tone and
the Body Location Selection
Screen will be displayed.
If the barcode cannot be
scanned, pressing the Manual
Patient ID button (Option C)
in the lower right corner will
allow you to manually enter
the Patient ID.
