Spire Tables, Single Frame.
REF:
Rectangular:
Square:
Circular:
Oval:
Read this leaflet before
assembly
COMPONENT PARTS
Item 2
Item 3
Curved Spire Leg
Rail
Qty, (See Table 1)
Qty, (See Table 1)
M/0794, M/0795, M/0796
M/0807
Item 4
Item 5
Expander Nut Plate
Grub Screw M8x35mm
Qty, (See Table 1)
Qty, (See Table 1)
A/1164
F/0627
1800 x 800mm, 2000 x 800mm,
2000 x 1000mm
1200 x 1200mm, 1400 x 1400mm
1200mm Dia, 1400mm Dia, 1600mm Dia
2000 x 1200mm, 2200 x 1200mm,
2400 x 1200mm
2 People
Required
Item 6
Pin M10 for Leveller
Qty, (See Table 1)
A/1162
Item 7
Item 8
Base of Leveller
Chipfast Bolt
Qty, (See Table 1)
Qty, (See Table 1)
A/1163
F/0486
No. 116 A/1885 Revision A 15/08/2018
1
Advertisement
Table of Contents
Related Manuals for Lee & Plumpton Spire Rectangular
Summary of Contents for Lee & Plumpton Spire Rectangular
- Page 1 www.leeandplumpton.co.uk ASSEMBLY INSTRUCTIONS RANGE Spire Tables, Single Frame. REF: Rectangular: 1800 x 800mm, 2000 x 800mm, 2000 x 1000mm Square: 1200 x 1200mm, 1400 x 1400mm Circular: 1200mm Dia, 1400mm Dia, 1600mm Dia Oval: 2000 x 1200mm, 2200 x 1200mm, 2400 x 1200mm Read this leaflet before 2 People...
- Page 2 COMPONENT PART QUANTITIES FOR UNIT SIZE VARIATIONS (TABLE 1) Rectangular Square W 1800 x W 2000 x W 2000 x W 1200 x W 1200 x ITEM ITEM D 800mm D 800mm D 1000mm D 1200mm D 1200mm 1087 1088 1089 1076 1077...
