www.leeandplumpton.co.uk
ASSEMBLY INSTRUCTIONS
RANGE
Duty, Delta with and without Modesty
REF:
1200mm
Read this leaflet before
assembly
COMPONENT PARTS
Item 1
Top Panel
Qty 1
Item 6
Item 7 *
Back Corner Leg
Delta Back Leg
Qty 1
Bracket
Qty 2
Item 8 & 9
Item 11
Cable Port
Rail Screw
Qty 4
Qty 12
A/0525 & A/0527
F/0587
Item 17 *
Item 18
Cam Cover
5/8" x 8g Pan Pozi
Qty 10
BZP
F/0436 F/0446 F/0545
Qty 10
F/0575 F/0576 F/0577
F/0414
* Desk with Modesty Panel only.
2 People
Required
Item 2 *
Delta Mod Panel LH
Qty 1
Item 21
Short Rail
Qty 2
Item 12
Item 13
Expander Plate
Grub Screws M8
Qty 4
Qty 8
A/1164
F/0637
Item 19 *
Item 20 *
Modesty Panel
12mm X M6
Spacer
Mushroom Head Bolt
Qty 10
Qty 4
R/0071
F/0441
Delta with modesty shown.
Item 3 *
Delta Mod Panel RH
Qty 1
Item 22
Rail
Qty 2
Item 14 *
Minifix Bolt Chipfast
34 x 15
Qty 8
F/0508
Item 23
Rail Bung For Delta
Desks
Qty 4
NP4/1177
No. 111 A/1880 Revision A 10/10/2018
Item 4
Item 5
GoalPost Frame RH
GoalPost Frame LH
Qty 1
Qty 1
Item 15 *
Item 16 *
Minifix M6
Minifix Alloy Cams
Qty 4
18mm
F/0433
Qty 10
F/0434
Item 24
5mm Hole Plugs
Qty 4
A/0518, A/0763,
F/0546
1
Advertisement
Related Manuals for Lee & Plumpton Duty 1200mm
Summary of Contents for Lee & Plumpton Duty 1200mm
- Page 1 www.leeandplumpton.co.uk ASSEMBLY INSTRUCTIONS RANGE Duty, Delta with and without Modesty REF: 1200mm Read this leaflet before 2 People assembly Required Delta with modesty shown. COMPONENT PARTS Item 1 Item 2 * Item 3 * Item 4 Item 5 Top Panel Delta Mod Panel LH Delta Mod Panel RH GoalPost Frame RH...
- Page 2 TOOLS REQUIRED BEFORE YOU BEGIN... • Pozi head screwdriver • Check you have all the tools and components required • 4mm Allen Key • Keep children and animals away from small parts • Ensure you have adequate space • Assemble product on a flat, clean surface •...
- Page 3 ASSEMBLY INSTRUCTIONS STEP 4 If a Modesty Panel is to be fitted, screw the Minifix Bolts (14) into the Top. Place the Spacers (19) over the Bolts. STEP 5 If a Modesty Panel is fitted, place Cams (16) in the holes in the Modesty Panels (2) &...
- Page 4 ASSEMBLY INSTRUCTIONS STEP 7 Screw the Grub Screws (13) into the Expander Plate through the hole in the Rail. Tighten the Grub Screws until the Expander Plate is pushed tight to the inside of the Rail. Fit the Cam Cover Caps (17). STEP 8 Carefully turn the Desk upright.
