AcomData mini Pal at a Glance

Aluminum Alloy Case Hi-Performance
Designed with the same Hard Drive
shape, footprint, material, and With a huge capacity for your
surface finish as Mac mini. demanding storage needs.
- 14 -
PushButton™
Press to initiate a backup.
Requires installation of the
included software.
12V 12V
5V 5V
GND GND
A A
POWER POWER USB 2.0 HUB
SWITCH PORT
This is where you can
You can turn The included AC connect your printer,
the mini Pal adapter plugs in scanner and other
on only when here. USB devices.
needed, to save
electricity.
- 15 -
B B
USB 2.0 FIREWIRE PORTS
TYPE B PORT
Use one port to connect
Used to connect mini Pal to your computer. Use
mini Pal to your the remaining two ports to add
computer. a whole arsenal of FireWire
(1394a) devices on up to two
daisy-chains.
