- Page 1 QuickStart Guide You personal, dedicated data storage warrior.
-
Page 2: Table Of Contents
3 Precautions 4 System Requirements 5 Connecting the Drive to your Computer 13 How to unmount & disconnect the Drive 14 Technical Specifications 14 Three-Year Limited Warranty 16 Obtaining Warranty Service 16 Contact AcomData 17 Notices 18 Registering your AcomData Product... -
Page 3: Package Contents
WelCome Welcome, and thank you for choosing an AcomData product. This guide covers all Samurai/ Samurai PRO models. When following the setup instructions, look for the instructions that best pertain to your model and situation. PaCkage Contents Please check your package contents. If any of the applicable items shown below are miss- ing, contact AcomData Customer Service at customerservice@acomdata.com. -
Page 4: Precautions
Please follow the precautions listed below. Not doing so could result in damage to the device and voiding of the warranty. • We strongly recommend you backup your data. AcomData is not responsible for data loss or corruption; nor will AcomData perform data recovery. •... -
Page 5: System Requirements
system requirements What WindoWs Users need: • Windows Vista, XP, or 2000 (SP4) • A free port for one of the interfaces that your Samurai may be equipped with. What Mac Users need: • G3, G4, G5 or Intel processor •... -
Page 6: Connecting The Drive To Your Computer
On the following pages you can find the connection option that pertains to your particular situation. When considering a connection option, please note: the following items are not supplied: • eSATA cable* • AC adapter* vAilAble for purchAse from ontAct customerservice AcomDAtA... -
Page 7: Connecting Via Usb
connecting via UsB Plug the primary USB type A connector into a USB port on your computer or self- powered USB hub. Plug the mini-USB connector into the Drive's mini-USB port. mini-USB port mini-USB connector Primary USB type A connector (plug into your computer) - Page 8 connecting via FireWire For this connection, your computer must have an available 6-pin FireWire port. Plug either end of the 6-pin to 6-pin FireWire cable into a 6-pin FireWire port on your computer. Plug the other end of the FireWire cable into the FireWire port on your Drive.
- Page 9 connecting via FireWire Using a 6-pin to 4-pin FireWire caBle and the UsB caBle Many laptops are equipped with 4-pin FireWire ports. However, 4-pin FireWire ports do not supply power. In this case, the FireWire connection will transmit the data; the USB connection will supply the power.
- Page 10 connecting via FireWire 800 For this connection, your computer must have an available 9-pin FireWire 800 port. Plug either end of the FireWire 800 cable into a 9-pin FireWire 800 port on your computer. Plug the other end of the FireWire cable into the FireWire 800 port on your Drive.
- Page 11 connecting via FireWire 800 Using a 9-pin to 4-pin FireWire caBle and the UsB caBle Many laptops are equipped with 4-pin FireWire ports. However, 4-pin FireWire ports do not supply power. In this case, the FireWire connection will transmit the data; the USB connection will supply the power.
- Page 12 connecting With an esata caBle and the UsB caBle eSATA ports do not supply power. If con- necting the Drive via eSATA, you must also connect the USB cable. The eSATA port will transfer the data; the USB port will supply the power.
- Page 13 veriFy that the drive MoUnts to yoUr systeM Windows users: A few moments after you connect the Drive, it should mount and a new drive icon/letter will appear in My Computer. Mac Users: A few moments after you connect the Drive, it should mount and a new drive icon will appear on the Desktop/Finder.
-
Page 14: How To Unmount & Disconnect The Drive
If your Samurai is equipped with a DC power port, you can use the optional AC adapter to power the Drive. This option is particularly useful for conserving laptop battery power. To purchase an AC adapter, contact customerservice@acomdata.com hoW to unmount & DisConneCt the Drive Windows Users In the Windows Taskbar, click the Safely Remove icon. -
Page 15: Technical Specifications
teChniCal sPeCifiCations Dimensions US (inches) ...5.43 x 3.42 x .75 Metric (mm) ... 138 x 87 x 19 Interface transfer rates (max) USB 2.0 ... 480 Mbps FireWire ... 400 Mbps FireWire 800 ... 800 Mbps eSATA ... 1.5 Gbps Ambient temperature / Relative humidity (non-condensing.) Operating ... - Page 16 incluDeD with the softwAre for your rights AnD obligAtions with respect to the softwAre ; (3) teries supplieD with this proDuct cosmetic DAmAges ; (5) storAge meDiA DAmAge Due to the roDuct such As roDuct ArrAnty Does not Apply if the mAlfunction results from proDucts or AncillAry or peripherAl equipment ;...
-
Page 17: Obtaining Warranty Service
A copy of the bill of sale for your AcomData product; A Returned Merchandise Authorization (RMA) number that is assigned to your product by an AcomData Tech Support Specialist. An RMA can only be generated if the product has been registered online at www.acomdata.com. You must register the product online or your TSS can register it for you. -
Page 18: Notices
notiCes opyrights © 2009. A opyright ll rights reserveD meAns electronic mechAnicAl photocopying rademarks ll trADemArks mentioneD or AppeAring in this Document Are the property of their respective owners hanges he mAteriAl in this Document is for informAtion only AnD subject to chAnge without notice been mADe in the prepArAtion of this Document to Assure its AccurAcy Document or from the use of the informAtion contAineD herein is AssumeD... -
Page 19: Registering Your Acomdata Product
ProDuCt Quickly register online at www.acomdata.com. Online registration is fast, free, and easy. You’ll get automatic software updates, unlimited free tech support, and up-coming services available only to online registrants. If you prefer to register by mail, complete both sides of the form on the next page. - Page 20 ProDuCt registration form Cut along the dotted line, fold and seal the form in a number 10 envelope, and mail to: acomData 901 east Cedar street ontario, Ca 91761 Name: E-mail: Company name: Address: City: State/Prov: Phone: Fax: Date of purchase (mm/dd/yy):...
- Page 21 Name of reseller: Model number: Serial number:...
