SECTION 3: WIRING AND INSTALLATION
Figure 3.27:- T200-410 and T200-510 600W Regeneration Resistor Option 2 – A76178-003 (Mounting and Connection)
Regeneration
Resistor Option/
Continuous
Rating
50Ohm/55W
(Internal)
10Ohm/750W
(External)
10Ohm/1kW
(External)
Table 3.5:- T200-410 and T200-510 Regeneration Resistor Options
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Actual Peak Regen
Continuous Power
Regen. Power
40W 2.8kW
600W 14kW
600W 14kW
T200 User's Manual
Regen Resistor AWG/(mm
Kit Part Number Wiring to connect
regen resistor
Already supplied No wiring needed
Internally!
C22654-006
(US only)
A76178-003
(Europe only)
2
)
20AWG/
2
(0.60mm )
2
1.50mm
PAGE 3-51
