Moog T200 User Manual page 154

SECTION 4 MOTOR GUIDE
Relevant standards for mechanical design
Standard
English
Degrees of protection provided by
enclosure (IP code)
Cylindrical shaft ends for electrical
machines
Mounting flanges for rotating electrical
machinery
Dimensions, tolerances and mounting
Tolerances of shaft extension run-out and of
mounting flanges for rotating electrical
machinery
Mechanical vibration, balance quality
requirements of rigid rotors, determination
of permissible residual unbalance
Mechanical vibration, balance quality
requirements of rigid rotors, Balance errors
Ball bearings, conrad type, for electrical
machines, tolerances and radial clearance
Drive type fastenings without taper action,
parallel keys, keyways, deep pattern
ISO general purpose metric screw threads.
Part 1 coarse pitch threads in diameter
range 1 mm to 68 mm, nominal sizes
General tolerances, tolerances for linear and
angular dimensions without individual
tolerance indications
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
International Europe
IEC EN CENELEC
International Europäisches
Electrotechnical Komitee für
Commission Elektrotechn.No
rmung
IEC 529 EN 60529
IEC 72
ISO/R 775-1969
IEC 72
ISO 1940-1
ISO 1940-2
ISO 724
ISO 2768-1 EN 22768
Table 4.11 Mechanical Design Standards
T200 User's Manual
Deutschland USA
DIN / VDE NEMA / NEC
Deutsche National
Industrie Norm / Electric Code
Verband MG.-...
Deutscher
Elektrotechniker
DIN EN 60529
VDE 0470-1
DIN 748-1 & 3 MG-11...
DIN 42948
NEMA
MG-7
DIN 42 955
DIN ISO 1940-1
DIN ISO 1940-2
DIN 42966
DIN 6885-1
DIN 13-1
DIN ISO 2768-1
PAGE 4-23
