GE and Console Connections

Cable Gland Adapter Assembly

The access points have two GE (Ethernet) ports and a Console port. During administration and
maintenance through the GE or Console port, the access points must still have a power connection
through an Ethernet PoE cable.
For information about the location of the GE and Console ports, see
Cable Gland Adapter Assembly
Before You Begin
Before connecting the RJ45 cable, a waterproof cable gland adapter assembly must be installed onto
the cable.
Figure 18: RJ45 cable gland adapter assembly
Callout
1
2
3
4
on page 37
Description
Sealing nut
Claw
Seal
Main body
