AP360i/e Power Tables

AP360i/e Power Tables
Table 4: AP360i power table
AP360i
Radio 0 (sensor)
Radio 0 (2.4G)
Radio 0 (5G–L)
Radio 1 (5G–F)
Radio 1 (5G–H)
BLE
GPS
Table 5: AP360e power table
AP360e
Radio 0 (sensor)
Radio 0 (2.4G)
Radio 0 (5G–L)
Radio 1 (5G–F)
Radio 1 (5G–H)
BLE
GPS

LED Indicators

There are six LEDs located on the front face of the access point but are not visibly marked.
12 ExtremeWireless™ AP360i/e Access Points
802.3af and 802.3at
2.4G:2×2 (23 dBm)
5G:2×2 (21 dBm)
2×2 (23 dBm)
2×2 (20 dBm)
2×2 (21 dBm)
2×2 (20 dBm)
On
On
802.3af and 802.3at
2.4G:2×2 (22 dBm)
5G:2×2 (19 dBm)
2×2 (22 dBm)
2×2 (18 dBm)
2×2 (19 dBm)
2×2 (18 dBm)
On
On
AP360i/e Overview
