Extreme Networks ExtremeWireless AP360i ExtremeWireless AP360e Installation Manual page 24

Install the Access Point on a Hard Vehicle Surface Using
the WS-MBV-VMM Vehicle Bracket (#32216)
Procedure
1. Using the vehicle assembly plate four long inner slots as a template, mark and drill the attachment
holes on a flat surface.
Figure 8: VMM vehicle attach assembly plate
Callout
1
2. Attach the vehicle attach assembly plate using four screws or bolts.
The screws or bolts must be tightened to hold the bracket and the access point in all environmental
conditions.
24 ExtremeWireless™ AP360i/e Access Points
Description
Inner slot on the VMM vehicle attach assembly plate
Install the Access Point
