2 Versions
2 Versions
As mentioned above, there are two models with different HF frontends (MIFARE and LEGIC) of the TWN4
Nano Module. In case of MIFARE it is available in three different versions, which support either both LF
(125kHz / 134.2kHz) and HF (13.56MHz), LF only or HF only. In case of LEGIC there is only the full version
with both LF (125kHz / 134.2kHz) and HF (13.56MHz). The following table lists all possible options.
Feature
TWN4 MultiTech
Nano Module
LF
HF
Table 2.1: Different features of TWN4 MultiTech Nano Module Versions
2.1 Color Marking
The different versions of the TWN4 Nano Module are marked with a color dot on the label.
TWN4 MultiTech
Nano Module HF
-
TWN4 MultiTech
Nano Module LF
-
TWN4 MultiTech
Nano Legic 42
Page 4 of 30
