Altronix eBridge4PCRM Installation Manual page 4

Parameter Description
Connections BNC for Coax link. RJ45 for ethernet link.
Input power
Midspan or endspan port connected.
requirements
Blue: Coax Link.
Yellow (RJ45 connector): On - Link, Off - No Link, Blinking - Activity.
Indicators
Green (RJ45 connector): On - 100Base-TX, Off - 10Base-T.
Green: Power.
Operating Ambient Temperature: UL60950-1
eBridge4PCRM:
eBridge1PCTX:
Environmental
eBridge1ST:
Conditions
Storage Temperature: -30º to 70ºC (-22º to 158ºF).
Relative humidity: 20 to 85%, non-condensing.
Operating Altitude: -1000 to 6,561.679 ft. (-304.8 to 2000m).
Regulatory UL/CUL Listed for Information Technology Equipment (UL 60950-1).
Compliance CE approved. C-Tick compliant.
Weights (approx.) Product: 1.35 lbs. (0.61 kg); Shipping: 1.7 lbs. (0.77 kg)
Maximum Length of Coax Type vs. Camera Power/PoE Class:
Camera
Power/ RG59/U - 23AWG RG59/U - 22AWG RG59/U - 20AWG RG59/U - 18AWG RG6/U - 18AWG
PoE Class
13W/0 260.6
4W/1
6.5W/2
13W/3 260.6
19W 152.4
25W 118.9
1 - Position and affix rubber pads (C) (included) at each corner on the bottom of the unit (Fig. 4).
2 - Place unit in desired location.
Fig. 4
C
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A.
IIeBridge4PCRM
- 4 -
Technical Specifications:
-20ºC to 49ºC (-4ºF to 120.2ºF).
For 15W: -40ºC to 75ºC (-40ºF to 167ºF).
For 30W: -40ºC to 49ºC (-40ºF to 120.2ºF).
For 15W: -40ºC to 75ºC (-40ºF to 167ºF).
For 30W: -40ºC to 65ºC (-40ºF to 149ºF).
335.3
500 500
500 500
335.3
198.1
150.6
Left Side
Rubber Pad
Coax Type
Max. Length (meters)
500
500
500
500
315.5
239.3
Shelf Installation
K21P
500
500
500
500
500
500
A
B
Mounting Hardware
Four (4) rubber pads.
C
500
500
500
500
500
365.8
(Included):
MEMBER
eBridge4PCRM
