Altronix eBridge4PCRM Installation Manual page 3

Fig. 2
Structured
Cable from
IP Camera/Device
Coax
Cable from
eBridge4PCRM
Fig. 1a
Fig. 3
Powered Switch or
NetWay MidSpan
eBridge4PCRM
eBridge1PCTX
eBridge1ST
Front
Structured
Cable from
Green LED
Camera/Device
indicates
PoE Out
to Device
Multiple PoE Camera Connection:
eBridge4PCRM
Rear
Flying BNC
Connector
PoC (PoE+ over Coax)
500m max.
PoC (PoE+ over Coax)
500m max.
PoC (PoE+ over Coax)
500m max.
PoC (PoE+ over Coax)
500m max.
Green LED
indicates
Power
Blue LED
indicates
Coax Connection
Flying BNC
Blue LED
indicates
Coax Link
is active
Transceiver
Transceiver
Transceiver
Transceiver
Connector
PoE compliant
100m max.
PoE Camera
PoE compliant
100m max.
PoE Camera
PoE compliant
100m max.
PoE Camera
PoE compliant
100m max.
PoE Camera
Legend:
Coax
Structured Cable
- 3 -
