LEDs with Selectable Jumpers
The CPLD Development/Programmer Board has eight individual LEDs, which allow designers to
display the output signals from the user I/Os of the ATF15xx devices. These eight LEDs are labeled
LED1 to LED8 on the CPLD Development/Programmer Board. The cathode of each LED is connected
to Ground (GND) through a series resistor, while the anode of each LED is connected to a user I/O pin
of the CPLD through the JPL1/2/3/4/5/6/7/8 selectable jumper. These jumpers can be removed to
disable the LEDs by unconnecting the anodes of the LEDs to the I/O pins of the CPLD. The figure
below illustrates the circuit diagram of the LEDs with the selection jumpers.
To turn on a particular LED, the corresponding ATF15xx I/O pin connected to the LED must be in a
logic high state with the corresponding jumper set; therefore, the outputs of the ATF15xx device will
need to be configured as active high outputs. The LEDs work best at 2.5V V
The lower pin count devices (44-pin) only have four I/Os connected to LED1/2/3/4. For the higher
pin-count devices (100-pin and larger), all eight LEDs are connected to the I/Os of the device.
shows the different package connections of the CPLD I/Os to the LEDs.
Figure 3.
RL1
330
LED1
GREEN
JPL1
SIP2
Table 3.
44-pin TQFP
LED
LED1
LED2
LED3
LED4
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Circuit Diagram of the LEDs and Jumpers
RL2
RL3
RL4
330
330
330
LED2
LED3
LED4
GREEN
GREEN
GREEN
JPL2
JPL3
JPL4
SIP2
SIP2
SIP2
ATF15xx Connections to LEDs
44-pin PLCC
PLD Pin
LED
28
LED1
25
LED2
22
LED3
19
LED4
ATF15xx-DK3-U Development/Programmer Kit [USER GUIDE]
RL5
RL6
330
330
LED5
LED6
GREEN
GREEN
JPL5
JPL6
SIP2
SIP2
84-pin PLCC
PLD Pin
LED
34
LED1
31
LED2
28
LED3
25
LED4
LED5
LED6
LED7
LED8
Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015
IO or higher.
CC
RL7
RL8
330
330
LED7
LED8
GREEN
GREEN
JPL7
JPL8
SIP2
SIP2
100-pin TQFP
PLD Pin
LED
69
LED1
67
LED2
64
LED3
60
LED4
27
LED5
24
LED6
18
LED7
15
LED8
Table 3
PLD Pin
68
65
63
58
17
14
10
9
7
