WEB GUI

8. WEB GUI
There are many features of ADTRAN's IP phones that can be more easily accessed using the GUI. The
following sections explain how to use the GUI to manage the IP 706/IP 712 phones.

Locating the IP Address of the Phone

Before you can access the GUI, you must locate your phone's IP address. To identify the IP address, use
these steps:
1. Press Menu.
2. Press 1 for Phone Status.
3. Press 2 for Network.
4. Using the arrow keys, scroll to the IP Address option.
5. Record the IP address for later reference.
6. Press the Exit soft key until the idle screen appears, or press CANCEL on the navigation bar to
return directly to the idle screen.

Accessing the Web Interface

Follow these steps to access the Phone Manager:
1. Enter this command into the address bar of your browser window:
http://<ip address>
where <ip address> is the IP address assigned to the phone.
2. Enter the login name and password.
The default login name is user and the default password is password. For more
information about changing login names and passwords, refer to Change Password on
page 48.
Some networks require browsers to use a proxy server to access the Internet. If you have problems
accessing the Web interface of the phone, it may be because the browser uses a proxy server. To bypass the
proxy server when accessing the phone's Web interface, follow these steps:
1. Open Microsoft
2. From the Tools drop-down menu, select Internet Options.
3. Select the Connections tab and select LAN Settings.
4. If Use a proxy server for your LAN is not selected and you are not using a proxy server, you can
quit at this step. If Use a proxy server for your LAN is selected, select Advanced.
5. In the Exceptions box, enter the IP address of your phone.
6. Select OK to close all of the dialog boxes.
44
®
Internet Explorer.
Copyright © 2011 ADTRAN, Inc.
ADTRAN IP 700 Series Phone User Manual
6AOSUG0001-1A
