2.2.24 F_Audio (Front audio header)

25
Pin 1
Front Audio Connector
2
10
Pin
Definition Pin
No.
No.
1
MIC_L
2
GND
3
MIC_R
4
Detect
5
HPOUT_R
10
1
9
Definition
6
GND
7
FAUDIO_JD
8
No Connect
9
HPOUT_L
GND
Connector PN
725-81-10TW00
A2004WV-2X05P46
www.gigaipc.com
Vendor
PINREX
JOINT-TECH
44
