dji MAVIC 2 ENTERPRISE Advanced User Manual
  1. Manuals
  2. Brands
  3. dji Manuals
  4. Quadcopters
  5. Mavic 2 Enterprise
  6. User manual

dji MAVIC 2 ENTERPRISE Advanced User Manual

Hide thumbs Also See for MAVIC 2 ENTERPRISE Advanced:
Table of Contents

Advertisement

Quick Links

MAVIC 2
ENTERPRISE
Advanced
User Manual
v1.0
2021.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAVIC 2 ENTERPRISE Advanced and is the answer not in the manual?

Questions and answers

Related Manuals for dji MAVIC 2 ENTERPRISE Advanced

Summary of Contents for dji MAVIC 2 ENTERPRISE Advanced

  • Page 1 MAVIC 2 ENTERPRISE Advanced User Manual v1.0 2021.03...
  • Page 2 Searching for Keywords Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search. Navigating to a Topic View a complete list of topics in the table of contents.

  • Page 3: Using This Manual

    * For increased safety, flight is restricted to a height of 98.4 ft (30 m) and range of 164 ft (50 m) when not connected or logged into the app during flight. This applies to DJI Pilot and all apps compatible with DJI aircraft.

  • Page 4: Table Of Contents

    Contents Using This Manual Legend Read Before the First Flight Download the DJI Pilot App Download DJI Assistant 2 (Enterprise Series) Product Profile Introduction Preparing the Aircraft Preparing the Remote Controller Diagram Activation Aircraft Flight Modes Aircraft LEDs and Status Indicator...
  • Page 5 DJI Pilot App Manual Flight Mission Flight Album Flight Flight Environment Requirements Flight Limits and GEO Zones Pre-Flight Checklist Starting/Stopping the Motors Flight Test Appendix Specifications Calibrating the Compass Updating Firmware After-Sales Information © 2021 DJI All Rights Reserved.
  • Page 6 Product Profile This section introduces Mavic 2 Enterprise Advanced and lists the components of the aircraft and remote controller. © 2021 DJI All Rights Reserved.

  • Page 7: Product Profile

    2.0, offering a maximum transmission range of 6.2 mi (10 km) and displaying video from the aircraft to DJI Pilot on a mobile device at up to 720p. The remote controller works at both 2.4 GHz and 5.8 GHz and can automatically select the best transmission channel without any latency.
  • Page 8 MAVIC 2 ENTERPRISE Advanced User Manual * Attach the gimbal cover when not in use. Gimbal clamp 1) Hold the gimbal in place and insert the gimbal clamp between the aircraft and the gimbal. 2) Make sure the hooks on the gimbal protector are locked in the grooves of the aircraft.

  • Page 9: Preparing The Remote Controller

    MAVIC 2 ENTERPRISE Advanced User Manual Preparing the Remote Controller Two pairs of control sticks are included in the packaging for the Smart Controller. One pair is stored in the sticks storage slot on the back of the remote controller. Follow the steps below to attach the control sticks stored in the sticks storage slot to the remote controller.

  • Page 10: Diagram

    MAVIC 2 ENTERPRISE Advanced User Manual Diagram Mavic 2 Enterprise Advanced (L1TE) 1. Forward Vision System 2. Propellers 3. Motors 4. Front LEDs 5. Gimbal and Camera A. Thermal Camera B. Visual Camera 6. Antennas 7. Backward Vision System 8. Aircraft Status Indicator 9.
  • Page 11 9. 5D Button Relays aircraft control and video signal. The default configuration is listed below. The configuration can be adjusted in DJI Pilot. 2. Back Button/Function Button Press once to return to the previous screen Up: Recenter gimbal/move gimbal downward...
  • Page 12 27. Customizable Button C1 The default configuration is center focus. 24. Sticks Storage Slot The configuration can be set in DJI Pilot. Use to store a pair of control sticks. 28. Air Intake 25. Customizable Button C2 Used for heat dissipation.

  • Page 13: Activation

    2. Connect the remote controller to the internet via Wi-Fi. After connecting, tap Next to continue and select the time zone, date, and time. 3. Log in with a DJI account. If you do not have an account, create a DJI account and log in. 4. Tap Activate on the activation page.
  • Page 14 Aircraft This section introduces the flight controller, Intelligent Flight Battery, and the Forward, Backward, and Downward Vision Systems. © 2021 DJI All Rights Reserved.

  • Page 15: Aircraft

    Intelligent Flight Battery. Refer to the aircraft diagram in the Product Profile section. Flight Modes Mavic 2 Enterprise Advanced has three flight modes, plus a fourth flight mode that the aircraft switches to in certain circumstances: P-mode (Positioning): P-mode works best when the GPS signal is strong. The aircraft utilizes GPS and the Vision Systems to locate itself, stabilize, and navigate between obstacles.

  • Page 16: Aircraft Leds And Status Indicator

    The Front LEDs show the orientation of the aircraft and glow solid red when the aircraft is powered on to indicate the front of the aircraft. Go to settings in DJI Pilot to turn the Front LEDs on or off.

  • Page 17: Return To Home

    Return home or land the aircraft immediately when prompted. DJI Pilot displays a warning prompt when the battery level is low. The aircraft will automatically return to the Home Point if no action is taken after a 10 second countdown.
  • Page 18 MAVIC 2 ENTERPRISE Advanced User Manual Aircraft Status Warning Scenario DJI Pilot App Actions Indicator Choose RTH or Select an option. If no Remaining battery level resume normal action is taken, the aircraft supports RTH. flight. will enter RTH. Select an option.
  • Page 19 During RTH, the orientation and direction of the aircraft cannot be controlled, but the remote controller or DJI Pilot can be used to control the speed and altitude. During RTH, obstacles on either side of the aircraft cannot be detected or avoided.

  • Page 20: Vision Systems And Infrared Sensing Systems

    RTH. When the current terrain matches the Home Point terrain, the aircraft will start landing. A prompt will appear in DJI Pilot if the aircraft is unable to match the terrain. Landing protection is available during precision landing.
  • Page 21 DJI Pilot or DJI Assistant 2 (Enterprise Series) for Mavic. The most accurate way to calibrate the Vision System cameras is by using DJI Assistant 2 (Enterprise Series) for Mavic. Follow the steps below to calibrate the Forward Vision System cameras and repeat the steps to calibrate other Vision System cameras.
  • Page 22 Make sure to maintain line of sight with the aircraft and pay attention to prompts in DJI Pilot. DJI takes no responsibility for any aircraft that is damaged or lost while using the Lateral Vision Systems.

  • Page 23: Flight Recorder

    Systems. Do not use any cleaning products that contains alcohol. c) Contact DJI Support if there is any damage to the glass of the Infrared Sensing and Vision Systems. The Upward Infrared Sensing System only detects in a straight line directly above the sensor and not the entire area above the aircraft.

  • Page 24: Attaching And Detaching The Propellers

    User Manual The password is stored in the aircraft only and will not be uploaded to the DJI server. Therefore, the aircraft needs to be reformatted if the password is lost. The data stored in the aircraft will be deleted once the aircraft is formatted.

  • Page 25: Intelligent Flight Battery

    11. Communication: information about the voltage, capacity, and current of the battery is transmitted to the aircraft. 12. Heating: the batteries of the Mavic 2 Enterprise Advanced are self-heating, enabling them to work in harsh and cold weather conditions as low as -4° F (-20° C).
  • Page 26 MAVIC 2 ENTERPRISE Advanced User Manual Refer to the Mavic 2 Intelligent Flight Battery Safety Guidelines before use. Users take full responsibility for all operations and usage. Using the Battery Battery Level LEDs Power Button High Checking Battery Level The battery level LEDs display how much charge is remaining. If the battery is powered off, press the power button to make the battery level LEDs light up to display the current battery level.
  • Page 27 41° to 104° F (5° to 40° C). The ideal charging temperature is 71.6° to 82.4° F (22° to 28° C). The Battery Charging Hub (not included) can charge up to four batteries. Visit the official DJI online store for more information.

  • Page 28: Gimbal And Camera

    Use the gimbal dial on the remote controller to control the tilt of the camera. Alternatively, enter the live view in DJI Pilot. Double tap to center or press the screen until a blue circle appears and drag the circle up and down to control the tilt of the camera and left and right to control the orientation of the aircraft.
  • Page 29 For Mavic 2 Enterprise Advanced, only the photos and videos recorded by the visual camera will have a timestamp and GPS info.

  • Page 30: Dji Airsense

    ADS-B out devices. 2. If there is an obstacle or steel structure between a manned aircraft and DJI aircraft, DJI AirSense will not be able to receive ADS-B messages sent by the manned aircraft or send warning prompts to the user.

  • Page 31: Modular Accessories

    MAVIC 2 ENTERPRISE Advanced User Manual Modular Accessories Mavic 2 Enterprise Advanced features an extended port for mounting additional compatible DJI modular accessories that are listed below: M2E Beacon: helps to identify aircraft during flight at night or in low light areas.

  • Page 32: Using The Rtk Module

    MAVIC 2 ENTERPRISE Advanced User Manual Make sure that the accessories are correctly and securely mounted on the aircraft before use. Otherwise, they may fall from the aircraft during flight. DO NOT point the spotlight or the beacon directly at people’s eyes.
  • Page 33 Smart Controller This section describes the features of the remote controller and includes instructions for controlling the aircraft and the camera. © 2021 DJI All Rights Reserved.

  • Page 34: Smart Controller

    The DJI Smart Controller uses DJI’s OcuSync 2.0 long-range transmission technology, offering a maximum transmission range of 6.2 mi (10 km) and displaying video from the aircraft to DJI Pilot on a mobile device at up to 720p resolution. The onboard buttons make controlling the aircraft easy and its detachable control sticks make it convenient to store.
  • Page 35 There are three pre-programmed modes as well as custom modes that can be configured in DJI Pilot. The modes are Mode 1, Mode 2, and Mode 3. The default mode is Mode 2. In each of the three pre-programmed modes, the aircraft hovers in place at a constant orientation when both sticks are centered.
  • Page 36 MAVIC 2 ENTERPRISE Advanced User Manual Mode 1 Left Stick Right Stick Forward Down Backward Left Right Turn Left Turn Right Mode 2 Left Stick Right Stick Forward Down Backward Left Right Turn Left Turn Right Mode 3 Left Stick...
  • Page 37 MAVIC 2 ENTERPRISE Advanced User Manual Remote Aircraft Controller Remarks Indicates Nose Direction) (Mode 2) Moving the left stick up or down changes the altitude of the aircraft. Push the stick up to ascend and down to descend. The more the stick is pushed away from the center, the faster the aircraft changes altitude.
  • Page 38 DJI Pilot. The functions of the C1 and C2 buttons are set in DJI Pilot. The default configuration for the C1 button is center focus and the default configuration for the C2 button is playback.

  • Page 39: Linking The Smart Controller

    Note that the illustrations above do not reflect the actual distances between the user and aircraft and are for reference only. A warning prompt appears in DJI Pilot if the transmission signal is weak. Adjust the antennas to make sure that the aircraft is within the optimal transmission range.

  • Page 40: Status Led And Battery Level Leds Description

    MAVIC 2 ENTERPRISE Advanced User Manual Make sure the antennas of the remote controller are unfolded and adjusted to the proper position to achieve optimal transmission quality. Repair or replace the remote controller if damaged. A damaged remote controller antenna greatly decreases performance.

  • Page 41: Smart Controller Warning Sounds

    MAVIC 2 ENTERPRISE Advanced User Manual Smart Controller Warning Sounds The Smart Controller will vibrate and/or beep when there is a warning prompt. If the error is related to the aircraft or flight status, the remote controller beeps and the status LED is solid green. If the error is related to the Smart Controller, a warning prompt will appear on the screen of the remote controller.
  • Page 42 DJI Pilot App This section introduces the main functions of the DJI Pilot app. © 2021 DJI All Rights Reserved.

  • Page 43: Dji Pilot App

    DJI Pilot App DJI Pilot is specifically developed for enterprise users and offers two types of flight. Manual flight integrates a variety of professional features that make flying simple and intuitive. Mission flight supports flight planning, and allows users to control the drone automatically, making workflows much simpler and more efficient.
  • Page 44 5. DJI AirSense Status : displays information about nearby manned aircraft to ensure flight safety, including the distance between DJI aircraft and manned aircraft. DJI AirSense will instruct users to land if nearby aircraft are detected. 6. GPS Signal Strength : displays the current GPS signal strength.
  • Page 45 MAVIC 2 ENTERPRISE Advanced User Manual 11. General Settings : tap to enter the General Settings to set units of measurement, enable or disable livestream, and more. 12. Display Mode Tap to switch between the Visible, IR, and Split display modes.
  • Page 46 MAVIC 2 ENTERPRISE Advanced User Manual 21. Map Tap to view the map. 22. Time and GPS Information Displays current date, time, and the longitude and latitude of the aircraft. Only available in Visible mode. 23. Accessory Shows if an accessory is connected such as the beacon...
  • Page 47 + 147.498992, - 122.274800 1. Palette : Mavic 2 Enterprise Advanced offers a variety of palette options. Distinct colors are used to show temperature differences in the thermal image, which are related to grayscale intensity. The temperature range of the image is mapped to 256 colors and displayed in 8-bit JPEG or MP4 format.
  • Page 48 MAVIC 2 ENTERPRISE Advanced User Manual b) Area Measurement: drag an area within the temperature measurement area on the screen. The average temperature, lowest temperature, highest temperature, and corresponding locations of this area will be displayed. The temperature measurement accuracy is affected by various factors: a) Reflectivity of objects –...

  • Page 49: Mission Flight

    MAVIC 2 ENTERPRISE Advanced User Manual Mission Flight Introduction Tap to enter the mission library. View created flight routes or the most recent Waypoint flights, Mapping missions, or Oblique Photography missions. Mapping and Oblique Photography missions are generated using the app and Waypoint flights can be created by selecting Set Waypoints or Live Mission Recording.
  • Page 50 4. Delete Selected Waypoint : tap to delete the selected waypoint. 5. Parameters List Edit the route name, set the aircraft type as Mavic 2 Enterprise Advanced, and configure the gimbal and camera. 6. Route Settings Route settings are applied to the entire route including action upon completion, gimbal control, and aircraft speed, height, and yaw.
  • Page 51 MAVIC 2 ENTERPRISE Advanced User Manual waypoint. The settings are applied to the selected waypoint including aircraft speed, height, yaw, longitude, latitude, and waypoint type and actions. 8. Mission Information Displays the flight length, estimated flight time, waypoint quantity, photo quantity, longitude, and latitude.
  • Page 52 MAVIC 2 ENTERPRISE Advanced User Manual 5. Clear Screen : tap to clear the flight path currently shown on the map. Live Mission Recording In-Flight（GPS） 2.4G 19:29 Shutter Shutter VISIBLE 1.0x 1/1000 1/1000 MENU Waypoints 1 SPLIT 00:05 VISIBLE 123456 123456 16.0...

  • Page 53: Album

    MAVIC 2 ENTERPRISE Advanced User Manual Album Jan27,2021 4:21:23 PM Single Shot (3 photos) Tap to view photos or videos that can be saved to a mobile device. When saving a photo or video, the format will vary depending on the display mode. Refer to the Storing the Photos and Videos section for more information.
  • Page 54 Flight This section describes safe flight practices and flight restrictions. © 2021 DJI All Rights Reserved.

  • Page 55: Flight

    Flight Altitude and Distance Limits The flight altitude and distance limits can be set in DJI Pilot. The maximum flight altitude setting cannot exceed 1,640 ft (500 m). Based on these settings, the aircraft will fly in a restricted cylinder as shown below.
  • Page 56 Only fly the aircraft within visual line of sight. GEO Zones All GEO Zones are listed on the DJI official website at http://www.dji.com/flysafe. GEO Zones are divided into different categories and include locations such as airports, flight areas where manned aircraft operate at low altitudes, international borders, and sensitive locations such as power plants.

  • Page 57: Pre-Flight Checklist

    8. Make sure all accessories are correctly and securely mounted on the aircraft before use. 9. Use only genuine DJI parts or parts certified by DJI. Unauthorized parts or parts from non-DJI certified manufacturers may cause system malfunctions and compromise safety.

  • Page 58: Flight Test

    1. Place the aircraft in an open, flat area with the Aircraft Status Indicators facing towards you. 2. Power on the aircraft and the remote controller. 3. Launch DJI Pilot and enter the live view. 4. Wait until the Aircraft Status Indicator blinks green indicating that the Home Point has been recorded and it is now safe to fly.
  • Page 59 Appendix © 2021 DJI All Rights Reserved.

  • Page 60: Appendix

    2.4-2.4835 GHz; 5.725-5.850 GHz Transmitter Power (EIRP) 2.4 GHz FCC: ≤26 dBm; CE: ≤20 dBm; SRRC: ≤20 dBm; MIC: ≤20 dBm 5.8 GHz FCC: ≤26 dBm; CE: ≤14 dBm; SRRC: ≤26 dBm Internal Storage 24 GB © 2021 DJI All Rights Reserved.
  • Page 61 MAVIC 2 ENTERPRISE Advanced User Manual Thermal Camera Sensor Uncooled VOx Microbolometer Focal Length Approx. 9 mm 35mm Format Equivalent: Approx. 38 mm Sensor Resolution 640×512 @30Hz Digital Zoom 16× Pixel Pitch 12 μm Spectral Band 8-14 μm Photo Format 640×512...
  • Page 62 MAVIC 2 ENTERPRISE Advanced User Manual Stabilization 3-axis (tilt, roll, pan) Max Controllable Speed 120°/s Angular Vibration Range ±0.005° Sensing System Sensing System Omnidirectional Obstacle Sensing (Forward) Horizontal: 40°, Vertical: 70° (Backward) Horizontal: 60°, Vertical: 77° (Downward) Front and Back: 100°, Left and Right: 83°...
  • Page 63 MAVIC 2 ENTERPRISE Advanced User Manual Operating Frequency 2.400-2.4835 GHz Transmission Power (EIRP) 4 dBm (FCC); 4 dBm (CE) 4 dBm (SRRC); 4 dBm (MIC) Others Battery 18650 Li-ion (5000 mAh @ 7.2 V) Charging Mode Charged with USB charger at 12 V/2 A...
  • Page 64 USB Micro-B Power Max. 10 W Decibel 100 dB at 1 m (international standard) Bit Rate 16 kbps * The DJI Smart Controller supports a microSD with a capacity of up to 128 GB. © 2021 DJI All Rights Reserved.

  • Page 65: Calibrating The Compass

    Choose an open area to carry out the following procedure. 1. Tap the System Status Bar in DJI Pilot, select Calibrate, and follow the on-screen instructions. 2. Hold the aircraft horizontally and rotate it 360°. The Aircraft Status Indicator will turn solid green.

  • Page 66: Updating Firmware

    Use DJI Pilot or DJI Assistant 2 (Enterprise Series) to update the aircraft firmware. Using DJI Pilot When the aircraft or remote controller is connected to DJI Pilot, a prompt will appear if a new firmware update is available. To update, connect the mobile device to the internet and follow the onscreen instructions.

  • Page 67: After-Sales Information

    If a firmware update is available, users will be prompted to update immediately or within three days. If the firmware update is ignored, users are required to agree to the disclaimer. The user’s decision not to update to the latest firmware is recorded to be uploaded and maintained on a DJI designated server.
  • Page 68 This content is subject to change. Download the latest version from www.dji.com/mavic-2-enterprise-advanced If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. MAVIC is a trademark of DJI. Copyright © 2021 DJI All Rights Reserved.
