Rainbow UAV flight control software user manual v.1.0
Rainbow UAV flight conrol
：DJI unmanned aircraft will encounter various problems in manual opera-
Introduction
tion. Sometimes, there is a little deviation in the ideal path to fly. Rainbow realizes automat-
ic flight. It can plan its own path, and the aircraft will fly automatically. It also adds some
custom photographing functions, panoramic photography, delay Camera, etc.
software
Software instruction manual
1
2
3
8
9
10
10
21
24
27
32
34
37
39
39
40
41
41
42

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAVIC 2 and is the answer not in the manual?

Questions and answers

Related Manuals for dji MAVIC 2

Summary of Contents for dji MAVIC 2

  • Page 1: Table Of Contents

    Rainbow UAV flight conrol software Software instruction manual ：DJI unmanned aircraft will encounter various problems in manual opera- Introduction tion. Sometimes, there is a little deviation in the ideal path to fly. Rainbow realizes automat- ic flight. It can plan its own path, and the aircraft will fly automatically. It also adds some custom photographing functions, panoramic photography, delay Camera, etc.

  • Page 2: 一、Open Rainbow App

    Rainbow UAV flight control software user manual v.1.0 ⼀一、Open Rainbow App 1. Find the Rainbow App icon on your desktop 2. Click the Rainbow icon to enter the app...

  • Page 3: 二、Enter The Connection Interface To Connect The Aircraft

    Rainbow UAV flight control software user manual v.1.0 ⼆二、Enter the connection interface to connect the aircraft 1.Enter the connection interface 1.1 Click“Connect Drone”button...
  • Page 4 Rainbow UAV flight control software user manual v.1.0 Click “How to connect to the drone”button，Go to the wizard to view the connection tutorial...
  • Page 5 Rainbow UAV flight control software user manual v.1.0 1.3 Follow the tutorial to connect the aircraft...
  • Page 6 Rainbow UAV flight control software user manual v.1.0 2．Connecting the aircraft 2.1 Install the battery and turn on the power to the remote control and the air- craft Turning on the aircraft: Find the intelligent flight battery switch,short press one and then long perss until the starting noise sounds.
  • Page 7 Rainbow UAV flight control software user manual v.1.0 2.2 Connect the aircraft to the remote control via a data cable Now Rainbow opens the connection and selects an app connection After connection, click “FLY Drone”button to enter the aircraft interface...

  • Page 8: 三、Ui Description Of Interface Basic Information

    Rainbow UAV flight control software user manual v.1.0 三、UI Description of interface basic information UI Interface basic operation instructions Status bar, mode switch, compass, preview window, camera components, feedback, and settings...

  • Page 9: 四、Switching Between Different Flight Modes

    Rainbow UAV flight control software user manual v.1.0 四、Switching between different flight modes • Click the "mode switching" button in the upper left corner to switch the mode There are currently seven flight modes • WAY POINT • ORBIT • HYPER LAPSE •...

  • Page 10: 五、Use Of Each Mode

    Rainbow UAV flight control software user manual v.1.0 五、Use of each mode 1. WAY POINT Click "mode switching" button to select waypoint mode 1.1Edit your own mission • Click "5. Edit mission" button to add waypoints and Camera points...
  • Page 11 Rainbow UAV flight control software user manual v.1.0 • Add waypoint Select "5.1. Waypoint editing" from the drop-down menu Add several points in the interface as flying points...
  • Page 12 Rainbow UAV flight control software user manual v.1.0 • Add Camera point Select "5.2. Camera point editing" from the drop-down menu Add the point you want to shoot in the interface...
  • Page 13 Rainbow UAV flight control software user manual v.1.0 • Start mission After setting, click the "3.Start mission" button Click "START" to start the mission...
  • Page 14 Rainbow UAV flight control software user manual v.1.0 • Terminate mission In case of any accident, click the "4. Terminate mission" button to end the current flight mission 1.2 Batch waypoint setting • If you do not want to set waypoints separately, you can choose to set way- points in batches Click "5.
  • Page 15 Rainbow UAV flight control software user manual v.1.0 Select "5.3. Batch waypoint setting" from the drop-down menu, draw the position to be flown, and the interface of "batch processing waypoint setting" will pop up. Set the distance and altitude, and click "OK", and the route will be automatically generated Set the Camera point Start / Terminate mission...
  • Page 16 Rainbow UAV flight control software user manual v.1.0 1.3 Set mission property • Click the "2. Set mission property" button to enter the setting interface • Waypoint mission setting 1. Head mode：POINT TO NEXT WAYPOINT、USING INITIAL DIRECTION、CON- TROL BY REMOTE CONTROLLER、USING WAYPOINT HEADING 2.
  • Page 17 Rainbow UAV flight control software user manual v.1.0 • Modify / delete flight waypoints Through the task attribute window, directly enter waypoint editing or click any waypoint in the planned route. You can edit the attribute of waypoint: Altitude, POI,Actions, or directly click the "delete" button in the upper left corner of the pop-up box to delete the current waypoint.
  • Page 18 Rainbow UAV flight control software user manual v.1.0 Clear all waypoints and Camera points • Click "6. Clear all" button to pop up "clear all". Click "OK" to delete all waypoints and Camera points Switch map mode • Click "8. Switch map mode" button to select the map mode from the drop-down menu...
  • Page 19 Rainbow UAV flight control software user manual v.1.0 1.4 Save task • Click "11. Save task" button It can save the current mission and continue to use it next time Input the task name and click "save"...
  • Page 20 Rainbow UAV flight control software user manual v.1.0 1.5 Open locally stored tasks • Click "10. Local tasks" button Select Open saved mission as flight route...

  • Page 21: Orbit

    Rainbow UAV flight control software user manual v.1.0 2. ORBIT Click "mode switching" button to select Orbit mode 2.1 Edit orbit mission • Select a location in the map and click...
  • Page 22 Rainbow UAV flight control software user manual v.1.0 • There will be a shooting icon and a yellow circle. The shooting is the center of the flight mission, and the outer circle is the flight path of the aircraft • Click "3. Start mission" button, and the aircraft will rotate 360 degrees along the trajectory after the mission starts...
  • Page 23 Rainbow UAV flight control software user manual v.1.0 • Click "4. Terminate mission" 2.3 Orbit mission property • Click "2.Set mission property" button or click the center surround point to open the "track mode setting" dialog box Aititude：- + Radius：- + Speed(deg/s)：- + Subject Height：- + Start point：North、South、West、East、Nearest...

  • Page 24: Hyper Lapse

    Rainbow UAV flight control software user manual v.1.0 3. HYPER LAPSE Click "mode switching" button to select Hyper Lapse mode • Delay mode is a photography mode. This mode is an enhancement on the basis of waypoint mode. Therefore, route planning and task attribute setting are the same as waypoint mode (refer to waypoint mode for specific operation) After starting the flight mission, click "7.
  • Page 25 Rainbow UAV flight control software user manual v.1.0 After shooting, click "end button" • • Video Preview After shooting, the video synthesis will be started automatically, and the preview video will be produced after waiting for a period of time...
  • Page 26 Rainbow UAV flight control software user manual v.1.0 Click "8. View delay photography video" button to view the last shot video •...

  • Page 27: Fpv

    Rainbow UAV flight control software user manual v.1.0 4. FPV Click "mode switching" button to select FPV mode • FPV means the first person perspective, so the mode is mainly manual operation 4.1 Take off • Click "1. Take off" button...
  • Page 28 Rainbow UAV flight control software user manual v.1.0 • A confirmation dialog box will pop up, and slide "slide to take off" to confirm takeoff...
  • Page 29 Rainbow UAV flight control software user manual v.1.0 4.2 Aircraft Return point 4.3 Nose course locking mode...
  • Page 30 Rainbow UAV flight control software user manual v.1.0 4.4 Aircraft return point locking mode 4.5 Tripod mode...
  • Page 31 Rainbow UAV flight control software user manual v.1.0 4.6 Switch speed • Click "8. Switch speed" button N：Switch to normal speed S：Switch to sport speed L：Switch to low speed...

  • Page 32: Follow Me

    Rainbow UAV flight control software user manual v.1.0 5. FOLLOW ME Click "mode switching" button to select Follow me mode 5.1 Follow me mode • Follow mode refers to the aircraft following an object with GPS positioning (mobile phone), after entering this mode, the mobile aircraft through the mobile phone will also follow the movement, and save a certain distance with you Usage: connect to the aircraft, enter the mode, start the aircraft manually, fly to the corresponding...
  • Page 33 Rainbow UAV flight control software user manual v.1.0 5.2 Follow me mission property • Follow me mission property Click “2.Set mission property” button to enter the setting interface and set the task properties Altitude：- + Subject Height：- + Head mode：TOWARD FOLLOW POSITION、CONTROLLED BY REMOTE CONTROLLER...

  • Page 34: Panorama

    Rainbow UAV flight control software user manual v.1.0 6. PANORAMA Click "mode switching" button to select panorama mode Set mission property • Panorama mission property Click “2.Set mission property” button to enter the setting interface and set the task properties Width（°）：- + Photos per row：- + Panorama Photo size：- +...
  • Page 35 Rainbow UAV flight control software user manual v.1.0 • Perform the shooting task After setting, fly the plane to the position you want to fly to, and click the "3. Start mission" button to perform the shooting task When the task is completed, open the download image. When the download is completed, the com- position task will be started automatically, and the picture can be previewed when the synthesis is completed.
  • Page 36 Rainbow UAV flight control software user manual v.1.0 • Panoramic image preview...

  • Page 37: Track

    Rainbow UAV flight control software user manual v.1.0 7. TRACK Click "mode switching" button to select Track mode 7.1 Select visual tracking target • Enter the visual tracking mode, frame out the target to be tracked with two fingers, select the track- ing target, turn on the tracking mode, and enter the visual tracking mode...
  • Page 38 Rainbow UAV flight control software user manual v.1.0 • After selecting the target, click "start icon" to start following the task 7.2 Track settings • Click “2.Set mission property” button Mode：Track、Profile、Spotlight Tracker Type：High Accuracy、Medium accuracy、Low accuracy...

  • Page 39: 六、Setting

    Rainbow UAV flight control software user manual v.1.0 六、Setting 1. Camera setting You can set the video format of the camera, white balance, display machine control to No Camera parameters can also be set in the aircraft interface...

  • Page 40: Aircraft Setting

    Rainbow UAV flight control software user manual v.1.0 Set the exposure parameters of the camera 2. Aircraft setting Set the maximum altitude of the aircraft, return altitude, distance limit, and switch of aircraft indicator light...

  • Page 41: General Setting

    Rainbow UAV flight control software user manual v.1.0 3. General setting Set the plane's screen to darken, auto zoom map, unit used, map type, language settings, feedback, and privacy terms. 4. Voice setting Set voice, height, distance, speed prompt on and off settings...

  • Page 42: 七、Put Forward Feedback Questions

    Rainbow UAV flight control software user manual v.1.0 七、Put forward feedback questions 1. This application provides a more convenient and simple flight control experience for DJI aircraft users 2. Problems encountered in use or new requirements can be raised through feedback 3.
