User Manual
1.5
Control panel user interface (Keypad and LEDs)
The SmartLoop control panel manages up 9 consoles, the main console is located on the control panel
frontplate (/G and /P models only), and up to 8 optional consoles (SmartletUSee/LCD Repeaters
connectable to the RS485 BUS).
D
E
PRE-ALARM
H
DISABLED
I
L
NIGHT MODE
M
TEST
Figure 1 - Control panel frontplate
1.5.1 Commands
Note:
For further details refer to the Programming Manual, Chapter 3 - The SmartLoop frontplate.
[1]
40 character x 4 line alphanumeric display. Indicates the system status, signals critical
events (priority given to the most serious events), and allows you to navigate through of
the main menu and screens.
, , ,
These keys allow you to navigate through the menu screens and change the values in the
[2]
programming fields.
The ESC key allows you to quit an operation and exit a screen, or step back to higher-level
[3]
ESC,
menu options. The
lower-level menu options.
[4]
Alphanumeric keypad for data entries. Key 1 allows you to view the specifics of events
which provide detailed information.
[5]
The keyswitch can be used as an alternative to authorized user codes (level 2).
[6]
If this button is pressed during active pre-alarm conditions (no key or code required - level
1), the system will generate an alarm. If this key is pressed during standby status when the
EVACUATION
key is in the keyswitch (Level 2), the system will generate an instant alarm.
This button (Active at level 2 only: this level requires key in keyswitch or code entry) clears
[7]
RESET
any active events, deletes the memory and restores standby conditions.
Description of the Control panel
1
STATUS
FAULTS
F
R
ALARM
FAULT
G
S
CPU FAULT
N
T
BATTERY
O
TEST
EARTH
P
FUSE
Q
ON
MAINS
BUZZER
INVESTIGATE
SILENCE
C
A
11
10
9
key allows you to confirm an operation and exit a screen, or go to
BELLS
DIALLER
U
ACTIVE
ACTIVE
V
FAULT
FAULT
W
DISABLED
DISABLED
Z
RESET
EVACUATE
B
8
6
7
2
Esc
3
1
2
3
abc
def
4
5
6
4
ghi
jkl
mno
7
8
9
LEV.2
pqrs
tuv
wxyz
0
LEV.1
.,
5
5
