This button (Active at level 2 only: this level requires key in keyswitch or code entry)
[8]
SILENCE
silences (switches Off) any active outputs with the silenceable attribute. The silenceable
outputs will hold silenced status until a new event occurs that releases the outputs
automatically. The SILENCE button operates as a toggle switch, therefore, silenced outputs
can be unsilenced by pushing the button again.
[9] If this button (Active at level 2 only: this level requires key in keyswitch or code entry) is
pressed during active pre-alarm conditions, the system will add the preset investigation
INVESTIGATE
time to the running pre-alarm time (this operation can be done once only).
This button (Active at level 1: no key or code entry required) silences the panel beeper.
[10]
BUZZER
This button (Active at level 1: no key or code entry required) activates all the console LEDs
[11]
TEST
in order to allow the operator to check functionality.
1.5.2 LED
Denomination
Indicates that the system has been silenced.
[A] LED
SILENCE
In the event of pre-alarm/alarm, indicates that reset
[B] LED
RESET
commands are not allowed. Reset will be allowed
when all outputs have been silenced and this LED
goes Off.
Indicates that investigation time has been
[C]
INVESTIGATE
requested.
LED
Indicates an alarm condition, that is, an input point
[D LED
ALARM
(detector, callpoint, input module, etc.) set to
generate alarms has detected alarm conditions.
Indicates a pre-alarm condition, that is, an input
[E]
PRE-ALARM
point (detector, callpoint, input module, etc.) set
LED
with a pre-alarm time has activated.
Indicates an active system fault condition. The
[F] LED
FAULT
display will provide the fault details.
Indicates trouble with the panel CPU—the panel
[G] LED
CPU
must be sent back immediately to the manufacturer
for repair.
Indicates that one or more of the system
[H] LED
BYPASS
components (loop point, zone or output) have been
bypassed.
Indicates that one or more components (points or
[I] LED
TEST
zones) are undergoing tests.
Indicates that the panel is operating in night mode.
[L] LED
NIGHT
Indicates the control panel is working.
[M] LED
ON
Indicates that a battery fault has been detected, the
[N] LED
BATTERY
display will provide the fault details (low battery,
battery disconnected).
6
ON Solid:
User Manual
ON Blinking:
Indicates memory of a cleared fault
event. To view the cleared fault
events details, consult the events
log using the Main menu (Level 1:
all building occupants).
Indicates that the CPU has re-
initialized (due to control panel
shutdown or fault condition). If this
occurs, it will be necessary to
check the functionality of the entire
system.
Indicates that the battery fault has
been cleared. The event details can
be viewed on the display via the
Main menu (Level 1: all building
occupants).
Description of the Control panel
