Denomination
Indicates voltage dispersion to earth.
[O] LED
EARTH
Indicates a short-circuit on one or more system
[P] LED
FUSE
devices (e.g. detectors). Call your installer for
immediate assistance!
Indicates electrical mains failure (primary power
[Q] LED
MAINS
source failure).
Indicates that the bell output is active.
[R]
BELLS -
LED
ACTIVE
Indicates that an alarm-signaling device is not
[S]
BELLS -
operating properly (e.g. bell out-of-order).
LED
FAULT
Indicates that one or more signaling outputs have
[T]
BELLS -
been disabled.
LED
BYPASSED
Indicates that the SmartLoop/PSTN board is sending
[U]
DIALLER -
an Alarm or Fault related report call.
LED
ACTIVE
Indicates a Dialler fault
[V]
DIALLER -
LED
FAULT
Indicates that one or more of the dialler functions
[W]
DIALLER -
have been bypassed.
LED
BYPASSED
[Z] Programmable The cause of activation of this LED can be defined
LEDs during the programming phase.
Description of the Control panel
ON Solid: ON Blinking:
Indicates that the voltage
dispersion to earth has been
cleared. The event details can be
viewed on the display via the Main
menu (Level 1: all building
occupants).
Indicates that the short-circuit on
one or more devices has been
cleared. The event details can be
viewed on the display via the Main
menu (Level 1: all building
occupants).
Indicates the mains failure has
been cleared. The event details can
be viewed on the display via the
Main menu (Level 1: all building
occupants).
Indicates that the alarm-signaling
device fault has been cleared. The
event details can be viewed on the
display via the Main menu (Level
1: all building occupants).
Indicates that the SmartLoop/PSTN
board is sending a technical
communication, monitoring
communication, etc.
Indicates that the Dialler fault has
been cleared. The event details can
be viewed on the display via the
Main menu (Level 1: all building
occupants).
