This command will allow you to access temporarily one of the control panels in the network from the
console you are working on. During this operating mode, the screens on the display will allow you to
monitor and command the remote control panel.
1 Co ntrol pane l 01
2 Co ntrol pane l 02
3 Co ntrol pane l 03
4 Con trol panel 04
Even t 001 of 003
PRE- ALARM
NORT H EAS T SEC TOR
Loop n°. 4
Note:
If the local control panel goes into alarm status while you are working on the remote console, the
remote connection will be interrupted and the screen of the local control panel will be reinstated.
2.7

View detector status

FROM PANEL
<any key>,
or <any key>,
This option will allow you to view the detector status and some parameter values.
Note:
You must wait several seconds for the control panel to retrieve the detector data.
Refer to the detector instructions for details.
Poin t x/yy y <
< De vice Type> Smok e : 0 .004 dB/m
Sens ibili ty :
Cont amina tion : 01%
Test Panel LEDs
Press <key>, Test LED, <OK>: all the panel LEDs will go On briefly.
Using the Control Panel
01/ 01/07 14:34 PM Fr i
W AREHO USE
CORR IDOR
poin t 147 Co ntrol pan el
2 Detector status, x loop, yyy detector
2xyyy
D escri ption
0.0 8dB/m
Press and to view the control panels
in the network.
Press in correspondence to the remote
q
control panel you wish to connect to. The
screen of the remote control panel will
appear after a few seconds.
The icon on the bottom right of the
display confirms
communicating with the selected remote
control, and that any commands entered
at the panel you are working on will be
implemented on the remote panel you
are communicating with. Press TEST to
go back to the local control panel.
Press keys
>
previous and next detectors.
that you are
and to view the
11
