6-4 C 6: C
HAPTER
Quit Install
Network Driver Optimization
Full Duplex
Media Type
Boot PROM
I/O Port Address
Interrupt Level
DMA Channel
Auto Configure
[ENTER]=<Auto Configure> Automatically Configures the Adapter
[Alt]+<Highlighted Key>=Execute Function
[TAB]=Next Field [SHIFT+TAB]=Previous Field [F1]=Help [ESC]=Cancel
Figure 6-2 Changing Adapter Configuration Screen
5 Press [Tab] to select the main dialog box. Use the
arrow keys to select a parameter option and
press [Enter].
A second dialog box appears.
6 Use the arrow keys to scroll through the list of
settings (see Table 6-1 for settings descriptions) for
that option. Select a setting and press [Enter].
Before changing any settings, consider the following:
If your PC has a plug and play BIOS, you cannot
change the I/O port address, interrupt level, or DMA
channel. These values are chosen by the BIOS.
Plug and play cannot be disabled.
If you are running Windows 95, you can change
configuration settings using the Windows 95
Control Panel. See your Windows 95 documentation

for more information.

C
HANGING ONFIGURATION
Configuration and Diagnostic Program
Test View Select
Adapter Configuration
EtherLink III Adapter Configuration
Modify File Options
S
ETTINGS
Normal
Disabled
Auto Select (N-Way)
Disabled
300h
10
7
OK
F1=Help
Cancel
