2-4 C 2: I
HAPTER
Mounting
screw
Expansion
slot cover
Figure 2-3 Removing the Screw and Backplate
9 Insert the 3C515-TX NIC into the empty expansion
slot, as shown in Figure 2-4, and secure it with the
screw you removed earlier.
Figure 2-4 Inserting the NIC
Make sure the board is firmly seated in the slot.
NIC
NSTALLING THE
Expansion
slots
